Siemens Signal Converter 3RS70061FW00 24-240 V AC/DC 3-Way Input mV/V/mA Output V/mA
Pricing
Request a quote
We reply within 24 hours
Product Description
Siemens 3RS70061FW00 universal signal converter with 3-way galvanic isolation, 24-240 V AC/DC supply, accepting mV, V or mA input ranges and providing V or mA outputs for process and measurement signalling. Housing 17.5 mm wide with screw connections for snap mounting on DIN rail, IP20 built-in device. Load 500 Ohm, temperature drift 0.015%/K, power consumption 0.5 W.
Technical Specifications
- Manufacturer part number (MPN)
- 3RS70061FW00
- EAN / GTIN
- 4047621001135
- Sales unit
- pcs
- Voltage
- 24-240 V
- Number of input ranges 0 mV ... 60 mV
- 1
- Number of input ranges 0 mV ... 100 mV
- 1
- Number of input ranges 0 mV ... 300 mV
- 1
- Number of input ranges 0 mV ... 500 mV
- 1
- Number of input ranges 0 V ... 1 V
- 1
- Number of input ranges 0 V ... 2 V
- 1
- Number of input ranges 0 V ... 5 V
- 1
- Number of input ranges 0 V ... 10 V
- 1
- Number of input ranges 0 V ... 20 V
- 1
- Number of input ranges 2 V ... 10 V
- 1
- Number of input ranges 0 mA ... 5 mA
- 1
- Number of input ranges 0 mA ... 10 mA
- 1
- Number of input ranges 0 mA ... 20 mA
- 1
- Number of input ranges 4 mA ... 20 mA
- 1
- Number of input ranges -5 mA ... +5 mA
- 1
- Number of input ranges -20 mA ... +20 mA
- 1
- Number of output ranges 0 V ... 10 V
- 1
- Number of output ranges 0 mA ... 20 mA
- 1
- Number of output ranges 4 mA ... 20 mA
- 1
- Number of channels
- 1
- SIL according to IEC 61508
- None
- Height
- 93 mm
- Width
- 17.5 mm
- Depth
- 72.5 mm
- Power consumption
- 0.5 W
- Load
- 500 Ohm
- Load influence
- 0 %
- Temperature drift
- 0.015 %/K
- Construction type of device
- Built-in device
- Type of electric connection
- Screw connection
- Mounting method
- Snap mounting support rail
- Degree of protection (IP)
- IP20
- Device construction
- Built-in device
- Country of origin
- Germany
Standards & Compliance
- HS Code
- 8538.90
Cross References
- EAN 4047621001135
- SAP 1000790541
- Code 81401900
Product Documentation
