Siemens Signal Converter 24-240V UC 3-Way Isolation In/Out 0-10V or 0/4-20mA

Siemens 3RS7005-2FW00 is a signal converter with a 24-240 V UC supply and 3-way galvanic isolation. Inputs and outputs cover 0-10 V and 0/4-20 mA ranges for analogue signal conditioning between sensors and control equipment. The compact 17.5 mm housing snaps onto DIN rail with spring-clamp terminals and IP20 protection.

Manufacturer part number (MPN)

3RS7005-2FW00

EAN / GTIN

4047621001272

Sales unit

pcs

Voltage

24-240 V

Number of input ranges 0 V ... 10 V

1

Number of input ranges 0 mA ... 20 mA

1

Number of input ranges 4 mA ... 20 mA

1

Number of output ranges 0 V ... 10 V

1

Number of output ranges 0 mA ... 20 mA

1

Number of output ranges 4 mA ... 20 mA

1

Number of channels

1

SIL according to IEC 61508

None

Height

93 mm

Width

17.5 mm

Depth

72.5 mm

Power consumption

0.5 W

Load

500 Ohm

Load influence

0 %

Temperature drift

0.015 %/K

Construction type of device

Built-in device

Type of electric connection

Spring clamp connection

Mounting method

Snap mounting support rail

Degree of protection (IP)

IP20

Device construction

Built-in device

Country of origin

Germany

HS Code

8538.90

• EAN 4047621001272
• SAP 1000790537
• Code 81402026
