Siemens Signal Converter 24-240 V UC 3-Way Isolated Multi-Range

Siemens 3RS7005-1FW00 is a 24-240 V AC/DC universal three-way isolated signal converter that accepts 0-10 V, 0-20 mA or 4-20 mA inputs and produces 0-10 V, 0-20 mA or 4-20 mA outputs on a single channel with 500 Ohm load capability. The unit occupies 17.5 mm on a snap-mount DIN rail with screw terminations, IP20 protection, and 0.5 W power consumption. Load influence is 0 % with a temperature drift of 0.015 %/K, and dimensions are 93 x 17.5 x 72.5 mm. Country of origin Germany.

Manufacturer part number (MPN)

3RS7005-1FW00

EAN / GTIN

4047621001098

Sales unit

pcs

Voltage

24-240 V

Number of input ranges 0 V ... 10 V

1

Number of input ranges 0 mA ... 20 mA

1

Number of input ranges 4 mA ... 20 mA

1

Number of output ranges 0 V ... 10 V

1

Number of output ranges 0 mA ... 20 mA

1

Number of output ranges 4 mA ... 20 mA

1

Number of channels

1

SIL according to IEC 61508

None

Height

93 mm

Width

17.5 mm

Depth

72.5 mm

Power consumption

0.5 W

Load

500 Ohm

Load influence

0 %

Temperature drift

0.015 %/K

Construction type of device

Built-in device

Type of electric connection

Screw connection

Mounting method

Snap mounting support rail

Degree of protection (IP)

IP20

Device construction

Built-in device

Country of origin

Germany

HS Code

8538.90

• EAN 4047621001098
• SAP 1000790533
• Code 81401983
