Siemens SIRIUS 3RT20 contactor, frame size S00 3RT2017-1AP02
Pricing
Request a quote
We reply within 24 hours
Product Description
Siemens 3RT2017-1AP02 — SIRIUS 3RT20 contactor, frame size S00. AC-3 rated up to 12 A at 400 V, 3-pole, screw or spring-cage terminals depending on -1A / -1B suffix. Contactor 12,5A, 230V AC 1NC.
Technical Specifications
- Manufacturer part number (MPN)
- 3RT2017-1AP02
- EAN / GTIN
- 4011209784994
- HS code
- 8536.90
- Sales unit
- pcs
- Width
- 45 mm
- Height
- 58 mm
- Depth
- 73 mm
- Rated operation power at AC-3, 400 V
- 5.5 kW
- Number of normally open contacts as main contact
- 3
- Number of auxiliary contacts as normally closed contact
- 1
- Rated operation current Ie at AC-3, 400 V
- 12 A
- Rated operation current Ie at AC-1, 400 V
- 22 A
- Type of electrical connection of main circuit
- Screw connection
- Operating voltage AC 50 Hz
- 690 V
- Operating voltage AC 60 Hz
- 690 V
- Voltage type for actuating
- AC
- Rated operation current Ie at AC-4, 400 V
- 8.5 A
- Rated operation power at AC-4, 400 V
- 4 kW
- Rated operation power NEMA
- 8 kW
- Country of origin
- Germany
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 4011209784994
- SAP 1000097697
- Code 8591422
Product Documentation
More from Siemens
Siemens
Siemens SENTRON 3VA9988-0AA23 — Changeover auxiliary switch (LCS)
Siemens
Siemens SIRIUS 3RV20 motor protection circuit breaker, frame size S00 3RV2011-1GA20
Siemens
Siemens Residual current circuit breaker A 25/2, torque 2,5-3,0 Nm, conductor cross-section 1-35 MM2, Short-Time Delayed K 5SV36126KK01
Siemens
Siemens Load-break switch 125A,size 2,3-Pole,operation side right-hand,box terminal for Cu cable
3KD3234-2NE40-0
Siemens
Siemens SENTRON 3VA9280-0WB00 — Auxiliary-circuit terminal, 3VA12
Siemens
Siemens SIMATIC S7 automation module 6ES7194-4GA00-0AA0
Siemens
Siemens MCCB_3VA21_3P_55KA_ETU350M,LSI,IN=40A,IR=16A-40A,ISD=3-15XIR,II=15XIN,B
3VA2140-5MN32-0AA0
Siemens
Siemens MCCB_3VA25_3P_110KA_ETU320,LI PROTECTION, IN=800A,IR=320A-800A, Tr=0,5-17 sek, II=1,5-10XIN, bolt
3VA2580-7HL32-0AA0
Technical guides
Catalogue entry last verified: 2026-09-29. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy 3RT2017-1AP02?
- 3RT2017-1AP02 can be ordered from cballast.com as a Siemens catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Siemens product?
- The manufacturer part number is 3RT2017-1AP02.
- What is the HS code for 3RT2017-1AP02?
- The customs tariff (HS) code for 3RT2017-1AP02 is 8536.90.
- Who manufactures 3RT2017-1AP02?
- 3RT2017-1AP02 is a Siemens product in the Electrical Components range.
- Is a datasheet available for 3RT2017-1AP02?
- Yes — the 3RT2017-1AP02 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for 3RT2017-1AP02?
- The minimum order quantity is 1.
- Is 3RT2017-1AP02 available?
- Yes — 3RT2017-1AP02 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
