Siemens JFA 1+N B20 30mA 10kA, meets NEK 400, residential IT/TN/TT
Pricing
Request a quote
We reply within 24 hours
Product Description
Siemens 5SU1354-6FM20 JFA 1+N B20 30 mA 10 kA, I2=1.3, meets NEK 400 for residential use, used in IT/TN/TT mains installations. Flush-mount 2-module residual current circuit breaker with overcurrent protection, Type A leakage current, B tripping characteristic, undelayed disconnection.
Technical Specifications
- Manufacturer part number (MPN)
- 5SU1354-6FM20
- EAN / GTIN
- 4001869484174
- Sales unit
- pcs
- Breaking capacity
- 10 kA
- Number of poles (total)
- 2
- Number of protected poles
- 2
- Rated voltage
- 230 V
- Rated insulation voltage Ui
- 264 V
- Rated impulse withstand voltage Uimp
- 4 kV
- Rated current
- 20 A
- Rated fault current
- 0.03 A
- Leakage current type
- A
- Current limiting class
- 3
- Rated short-circuit breaking capacity according to EN 61009
- 10 kA
- Disconnection characteristic
- Undelayed
- Surge current capacity
- 1 kA
- Voltage type
- AC
- Frequency
- 50 Hz
- Release characteristic
- B
- Overvoltage category
- 3
- Pollution degree
- 2
- Width in number of modular spacings
- 2
- Built-in depth
- 70 mm
- Degree of protection (IP)
- IP20
- Flush-mounted installation
- Yes
- Country of origin
- Romania
Standards & Compliance
- HS Code
- 8536.20
Cross References
- EAN 4001869484174
- SAP 1000633982
- Code 8151324
Product Documentation
