Product Description
Siemens 5SM2425-6 Residual current circuit breaker block for miniature circuit breakers (MCBs). 2P 63A 100MA.
Technical Specifications
- Manufacturer part number (MPN)
- 5SM2425-6
- EAN / GTIN
- 4001869194110
- HS code
- 8536.90
- Sales unit
- pcs
- Nominal voltage
- 230 V
- Nominal current
- 63 A
- Rated fault current adjustable
- No
- Rated fault current
- 100 A
- Delay adjustable
- No
- Number of poles
- 2
- Leakage current type
- A
- Surge current capacity
- 4000 kA
- Frequency
- 50 Hz
- Rated insulation voltage Ui
- 460 V
- Rated impulse withstand voltage Uimp
- 1 kV
- Connectable conductor cross section solid-core
- 1.5–25 mm²
- Connectable conductor cross section multi-wired
- 1.5–25 mm²
- Anti-nuisance tripping version
- Yes
- With interlocking device
- No
- Degree of protection (IP)
- IP20
- Pollution degree
- 2
- Ambient temperature during operating
- -25–45 °C
- Country of origin
- Czechia
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 4001869194110
- SAP 1200358517
- Code 82369701
