Siemens 5SD7461-1
Pricing
Request a quote
We reply within 24 hours
Overview
Siemens 5SD7461-1 is listed under Switchgear & Protection / Surge Protectors. Sales unit: pcs; System configuration DC: No; System configuration IT: No; System configuration TN: No; System configuration TN-C: No; System configuration TT: No.
Technical Specifications
- Manufacturer part number (MPN)
- 5SD7461-1
- EAN / GTIN
- 4001869340593
- Sales unit
- pcs
- System configuration DC
- No
- System configuration IT
- No
- System configuration TN
- No
- System configuration TN-C
- No
- System configuration TT
- No
- System configuration other
- No
- Number of conductors (without earthing)
- 1
- Nominal discharge surge current (8/20)
- 40 kA
- Max. discharge surge current (8/20)
- 40 kA
- Nominal voltage AC
- 230 V
- Max. continuous voltage AC
- 350 V
- Voltage protection level
- 1.4 kV
- Short-circuit breaking capacity (Isccr)
- 25 kA
- Integrated short-circuit protection
- No
- Integrated backup fuse
- No
- Mounting method
- DIN rail (top hat rail) 35 mm
- Construction size
- 1 modular spacing
- Max. conductor cross section solid (solid, stranded)
- 35 mm²
- Max. conductor cross section flexible (fine-strand)
- 25 mm²
- With remote signalling contact
- Yes
- Signalling at the device
- Optical
- Category type 2
- Yes
- Degree of protection (IP)
- IP20
- Country of origin
- Germany
Standards & Compliance
- HS Code
- 8536.30
Cross References
- EAN 4001869340593
- SAP 1000324376
- Code 8352440
