NANO Driver DC 17W 350MA PHASE/Pushdim
Part number820091EAN / GTIN7021988200919HS code8504.31
Lighting & Electrical Accessories
LED Drivers
MOQ:1
Pricing
Request a quote
We reply within 24 hours
Product Description
SG Armaturen 820091 Driver DC 17W Phase-cut/Pushdim.
Technical Specifications
- Manufacturer part number (MPN)
- 820091
- EAN / GTIN
- 7021988200919
- Sales unit
- pcs
- Package quantity
- 10 pcs
- Power
- 17 W
- Wattage
- 17W
- IP Class
- IP20
- Mounting
- Indoor
- Function
- Ambient temperature range ta -20 …+45°C
- System wattage
- 17W
- Voltage
- 220-240V
- Max. luminaires per circuit breaker
- B10: 32, B16: 50, C10: 52, C16: 85
- Type
- Trailing edge / Push Dim
- Driver
- 350mA
- Breeam
- Fulfils Hea 01 for flicker free lighting
- Housing
- Plastic
- Colour
- White
- Length (mm) L
- 166
- Width (mm) W
- 46
- Height (mm) H
- 34
- Weight (kg) gross/net
- 1 / 0.28
- Packaging dimensions (mm)
- 170 x 80 x 45
- Operation by Bluetooth
- No
- Compatible with Casambi
- No
- Model
- Static
- Suitable for outdoor use
- No
- Dimming 0-10 V
- No
- Dimming 1-10 V
- No
- Dimming DALI
- No
- Dimming DSI
- No
- Dimming DMX
- No
- Dimming potentiometer (integrated)
- No
- Dimming GPRS
- No
- Dimming LineSwitch
- No
- Dimming manufacturer's proprietary system
- No
- Dimming mains voltage modulation
- No
- Dimming phase cut-off (trailing edge)
- Yes
- Dimming phase cut-on (leading edge)
- No
- Dimming programmable
- No
- Dimming RF
- No
- Dimming Its Wave Reduction
- No
- Dimming Touch and Dim
- No
- Dimming Zigbee
- No
- Dimming with push-button
- Yes
- No dim function
- No
- Suitable for constant current
- No
- Suitable for constant voltage
- Yes
- Output voltage
- 24 V
- Output current
- 125–850 mA
- Suitable for DC-voltage (primary side)
- No
- Output power
- 3–20 W
- Degree of protection (IP)
- IP20
- Protection class according to IEC 61140
- II
- Length
- 166 mm
- Width
- 46 mm
- Height
- 34 mm
- Compatible with Apple HomeKit
- No
- Compatible with Google Assistant
- No
- Compatible with Amazon Alexa
- No
- IFTTT support available
- No
- Dimmable
- Yes
- Dimming DALI-2
- No
- Country of origin
- Italy
Standards & Compliance
- HS Code
- 8504.31
Cross References
- EAN 7021988200919
- SAP 1200075286
- Code 81921724
Product Documentation
Document preview: NANO Driver DC 17W 350MA PHASE/Pushdim (820091) — Specification sheet
