Product Description
Sferaco 1170 Butterfly valve GGG40/Epoxy/EPDM Wafer double-acting. Butterfly valves with actuator (Technique / Industrial valves / Butterfly valves). Principal data: dn dimension 250, pressure pn 16 bar. Supplied under manufacturer part number 10402676, HS code 8481.80, country of origin Denmark.
Technical Specifications
- Product type
- Butterfly valves with actuator
- Product group
- Industrial valves
- DN dimension
- 250
- Pressure PN
- 16 bar
- Temperature max
- 110 °C
- Temperature min
- -10 °C
- Length built-in dimension
- 68 mm
- House
- Cast iron GGG40
- Disc / dampers
- Epoxy-coated (250my) cast iron GGG40
- Liner / packing
- EPDM
- Actuator
- PA140DA 513 nm
- Top flange
- F10 -22 mm
- ISO top flange
- 5211
- Breakaway torque
- 323 nm
- Country of origin
- Denmark
- Customs tariff code (EU CN)
- 84818085
- HS code
- 8481.80
- Manufacturer part number
- 10402676
Standards & Compliance
- HS Code
- 8481.80
Cross References
- MPN 10402676
