Schneider LX1FH Coil - TeSys F

Schneider LX1FH Coil. Contactors and thermal relays (Electrical Engineering / Components for panels and boxes). Principal data: series TeSys F. Supplied under manufacturer part number LX1FH0422, EAN 3389110454147, HS code 8504.50, country of origin Czechia.

Product type

Contactors and thermal relays

Product group

Components for panels and boxes

Series

TeSys F

Carbon footprint (EPD)

4.3502 kg CO2e per pcs

Country of origin

Czechia

Customs tariff code (EU CN)

85045000

HS code

8504.50

Manufacturer part number

LX1FH0422

Range

TeSys

Product or component type

Contactor coil

Device short name

LX1FH

Range compatibility

TeSys TeSys F LC1F contactor

Product compatibility

LC1F330; LC1F265

Control circuit type

AC at 50/60 Hz

[Uc] control circuit voltage

42 V AC 50/60 Hz

Average resistance

0.8 Ohm inrush at 20 °C; 20 Ohm holding at 20 °C

Operating time

100...170 ms opening; 40...65 ms closing

Mechanical durability

10 Mcycles

Maximum operating rate

2400 cyc/h 55 °C

Coil technology

Without built-in suppressor module

Control circuit voltage limits

Drop-out: 0.35...0.55 Uc 50/60 Hz (at 55 °C); Operational: 0.85...1.1 Uc 50/60 Hz (at 55 °C)

Inrush power in VA

650 VA 50/60 Hz cos phi 0.9 (at 20 °C)

Hold-in power consumption in VA

10 VA 50/60 Hz cos phi 0.3 (at 20 °C)

Heat dissipation

8 W at 50/60 Hz

Ambient air temperature for operation

-5…55 °C

Product weight

0.75 kg

Number of Units in Package 1

1

Warranty (in months)

18

EAN

3389110454147

HS Code

8504.50

• EAN 3389110454147
• MPN LX1FH0422
