Schneider LAD4 Diode - TeSys D
Pricing
Request a quote
We reply within 24 hours
Product Description
Schneider LAD4 Diode. Contactors and thermal relays (Electrical Engineering / Components for panels and boxes). Principal data: series TeSys D. Supplied under manufacturer part number LAD4TBDL, EAN 3389118025462, HS code 8541.10, country of origin France.
Technical Specifications
- Product type
- Contactors and thermal relays
- Product group
- Components for panels and boxes
- Series
- TeSys D
- Voltage
- 24 V DC
- Carbon footprint (EPD)
- 0.0139 kg CO2e per pcs
- Country of origin
- France
- Customs tariff code (EU CN)
- 85411000
- HS code
- 8541.10
- Manufacturer part number
- LAD4TBDL
- Range
- TeSys
- Device short name
- LAD4
- Product or component type
- Suppressor module
- Product compatibility
- 3P LC1D09...D38; 4P LC1DT20...DT40; 4P LC1D098...D258; CAD32, CAD50
- Mounting location
- Side
- mounting mode
- By clips
- Suppressor technology
- Bidirectional peak limiting diode
- [Uc] control circuit voltage
- 24 V DC
- Maximum peak voltage
- 2 Uc
- Product weight
- 0.012 kg
- Standards
- IEC 60947-5-1; EN 60947-5-1; CSA C22.2 No 60947-5-1; UL 60947-5-1; GB/T 14048.5
- Product certifications
- UL; CSA
- IP degree of protection
- IP2X conforming to IEC 60529
- Ambient air temperature for operation
- -25…55 °C
- Ambient air temperature for storage
- -40…80 °C
- Number of Units in Package 1
- 1
- Number of Units in Package 2
- 120
- Number of Units in Package 3
- 1920
- Warranty (in months)
- 18
- EAN
- 3389118025462
Standards & Compliance
- HS Code
- 8541.10
Cross References
- EAN 3389118025462
- MPN LAD4TBDL
