Schneider Electric voltage control relay iRCU - 8 A - 230 V 50/60Hz - 1 OC A9E21182

iRCU voltage monitoring relay for measuring overvoltage, undervoltage and voltage loss.

Manufacturer part number (MPN)

A9E21182

EAN / GTIN

3606480377518

Sales unit

pcs

Voltage

230 V AC

Rated current

8 A

Range of product

Acti9

Product name

Acti9 iRC

Product or component type

Control relay

Device short name

iRCU

Device application

Voltage control relay

Signal contacts composition

1 C/O

[Ie] rated operational current

8 A at 250 V AC 50/60 Hz (cos Phi = 1)

Local signalling

Reports when the preset threshold is reached; Red LED for fault; Green LED for power on

Type of setting

Selected by wiring: measurement range; Switch: overvoltage; Switch: undervoltage

Tripping threshold

10...100 %

Analogue input range

50...500 V AC; 10...100 V DC; 50...500 V DC; 10...100 V AC

Hysteresis

5…50 %

Time delay range

0.1...10 s

Accuracy error

+/- 10 %

[Us] rated supply voltage

230 V AC at 50/60 Hz

Power consumption in VA

3 VA

Mounting mode

Fixed

Mounting support

35 mm symmetrical DIN rail

9 mm pitches

4

Height

88.1 mm

Width

36 mm

Depth

67 mm

Product weight

0.215 kg

Col

HS Code

8536.49
