Schneider Electric Actassi OPB Open Wall-Mount Cabinet 12U 600x400 RAL 7035

Schneider Electric NSYOPB12U4FR is an Actassi OPB open-box wall-mounted 19" cabinet with 12U rack space, external dimensions 600 x 650 x 400 mm and a plain front door with 1-point key lock (333). The sheet-steel structure with epoxy-polyester powder finish in light grey RAL 7035 carries IK10 impact and IP20 ingress ratings, with removable side, top, bottom and rear panels and 50 kg static load. It is used to mount and protect network switches, patch panels and small server equipment.

Manufacturer part number (MPN)

NSYOPB12U4FR

EAN / GTIN

3606480287602

Sales unit

pcs

Package quantity

6 pcs

Range

Actassi

Product name

Actassi OPB

Product or component type

19" enclosure

Device application

Cabling

applications

To protect network connectivity equipment; To mount 19" equipment; To improve security of the equipment

enclosure type

Open box

support equipment

2 x fixed 19" uprights recessed of 120 mm from the front (pitch 25 mm)

front face

Plain door

Door type

Front plain door - with 1 point locking system (key: 333) - reversible opening at 180 °

Accessibility for operation

Side; Front; Rear

Removable parts

Front door removable toolless; Top blanking plate; Bottom blanking plate; Rear blanking plate; Side panels removable toolless

colour

Light grey (RAL 7035)

Device composition

3 x cable entries; 2 x panels side; 2 x 19" uprights front; 1 x open structure; 1 x plain door front

load rating

50 kg static; 3 kg by unit

back face

Cut-out

side face

Panel

Number of cut-out

1 cut-outside; 1 cut-outbottom; 1 cut-outtop

installation mode

Wall mounted

Material

Sheet steel: structure; Sheet steel: door; Galvanized steel: upright

Surface finish

Epoxy-polyester powder

Width

600 mm

Height

650 mm

Depth

400 mm

Product weight

22 kg

Number of rack unit

12U

Targeted region

Europe

IK degree of protection

IK10 conforming to IEC 62262

IP degree of protection

IP20 conforming to IEC 60529

Standards

IEC 60297-3-100; EIA-310D

Number of Units in Package 1

1

Number of Units in Package 2

6

Warranty (in months)

18

Mounting level

Front and rear

Model

With permanent frame

Type of profile rail

None

Number of doors

1

Type of ventilation

None

Number of height units

12

Max. load capacity

50 kg

With roof plate

Yes

With earthing

No

With front door

Yes

With sidewall

Yes

Demountable

Yes

Surface finishing

Powder coating

RAL-number

7035

Degree of protection (IP)

IP20

Country of origin

Romania

HS Code

9403.20
