Schneider Electric Actassi Wall-Mounted Open 19 in Cabinet 9U W600 D400 R7035

Schneider Electric NSYOPB9U4FR is a 9U 19-inch wall-mount cabinet in the Actassi OPB range, 600 mm wide and 400 mm deep. Two fixed 19-inch uprights, recessed 120 mm from the front, mount active and passive network equipment behind a plain, key-locked front door. The IP20 / IK10 open-box enclosure is finished in light grey (RAL 7035) with side, front and rear access for cabling and maintenance.

Manufacturer part number (MPN)

NSYOPB9U4FR

EAN / GTIN

3606480287596

Sales unit

pcs

Package quantity

9 pcs

Range

Actassi

Product name

Actassi OPB

Product or component type

19" enclosure

Device application

Cabling

applications

To mount 19" equipment; To improve security of the equipment; To protect network connectivity equipment

enclosure type

Open box

support equipment

2 x fixed 19" uprights recessed of 120 mm from the front (pitch 25 mm)

front face

Plain door

Door type

Front plain door - with 1 point locking system (key: 333) - reversible opening at 180 °

Accessibility for operation

Rear; Front; Side

Removable parts

Front door removable toolless; Top blanking plate; Bottom blanking plate; Rear blanking plate; Side panels removable toolless

colour

Light grey (RAL 7035)

Device composition

3 x cable entries; 2 x panels side; 2 x 19" uprights front; 1 x open structure; 1 x plain door front

load rating

50 kg static; 3 kg by unit

back face

Cut-out

side face

Panel

Number of cut-out

1 cut-outside; 1 cut-outbottom; 1 cut-outtop

installation mode

Wall mounted

Material

Sheet steel: structure; Sheet steel: door; Galvanized steel: upright

Surface finish

Epoxy-polyester powder

Width

600 mm

Height

515 mm

Depth

400 mm

Product weight

18.66 kg

Number of rack unit

9U

Targeted region

Europe

IK degree of protection

IK10 conforming to IEC 62262

IP degree of protection

IP20 conforming to IEC 60529

Standards

EIA-310D; IEC 60297-3-100

Number of Units in Package 1

1

Number of Units in Package 2

9

Warranty (in months)

18

Mounting level

Front and rear

Model

With permanent frame

Type of profile rail

None

Number of doors

1

Type of ventilation

None

Number of height units

9

Max. load capacity

50 kg

With roof plate

Yes

With earthing

No

With front door

Yes

With sidewall

Yes

Demountable

Yes

Surface finishing

Powder coating

RAL-number

7035

Degree of protection (IP)

IP20

Country of origin

Romania

HS Code

9403.20

• EAN 3606480287596
• SAP 1000396493
• Code 81091990
