Schneider Electric SpaceLogic KNX Fan Coil Actuator REG-K

Schneider Electric MTN645094 is a SpaceLogic KNX fan coil actuator in DIN-rail housing that regulates heating and cooling in two- and four-pipe fan-coil systems. It provides three switching outputs at 16 A and two at 0.5 A for valve control, plus two binary SELV inputs, and operates on the KNX bus with local manual override. The four-module light-grey enclosure clips onto a standard 35 mm rail with IP20 protection. Typical application is room climate control in offices and hotel rooms using fan-coil units.

Manufacturer part number (MPN)

MTN645094

EAN / GTIN

3606485100029

Sales unit

pcs

Package quantity

10 pcs

Range

SpaceLogic KNX

Product or component type

Fan coil actuator

Bus type

KNX

Operating mode

Manual; KNX bus system

Output current

16 A - 3 x for output switching on/off; 0.5 A - 2 x for output switching on/off

Input function

Signal voltage (SELV): 2 x binary

Colour tint

Light grey

Power supply input current

12 mA

Wiring device mounting

DIN rail

Number of outputs

5

[Ue] rated operational voltage

207...253 V

Load type

Valve: 230 V AC; Valve: 24 V AC

total number of 18 mm modules

4

IP degree of protection

IP20

Unit Type of Package 1

PCE

Number of Units in Package 1

1

Package 1 Height

8.200 cm

Package 1 Width

9.300 cm

Package 1 Length

10.600 cm

Package 1 Weight

308.000 g

Unit Type of Package 2

CAR

Number of Units in Package 2

24

Package 2 Height

30.200 cm

Package 2 Width

31.300 cm

Package 2 Length

40.900 cm

Package 2 Weight

7.824 kg

Country of origin

DE

Warranty (in months)

18

Other bus systems

None

Mounting method

DRA (DIN-rail adaptor)

Width in number of modular spacings

4

Max. switching current (resistive load)

0.5 A

Max. output current

0.5 A

Degree of protection (IP)

IP20

HS Code

8536.50

• EAN 3606485100029
• SAP 1000325168
• Code 8725092
