Schneider Electric RS-232 ZigBee interface, SpaceLogic HNW, Hybrid Module, white LSS100400
Pricing
Request a quote
We reply within 24 hours
Product Description
Schneider Electric LSS100400 — RS-232 ZigBee interface, SpaceLogic HNW, Hybrid Module, white.
Technical Specifications
- Manufacturer part number (MPN)
- LSS100400
- EAN / GTIN
- 3606482215801
- Sales unit
- pcs
- Package quantity
- 16 pcs
- Range
- SpaceLogic KNX
- Product or component type
- RS-232 ZigBee interface
- Colour tint
- White
- Communication port protocol
- Zigbee 3.0; RS232 serial link
- [Us] rated supply voltage
- 24 V DC
- Power consumption in W
- 0.3 W
- LED indicator
- LED (green/red) for transmission/reception activity (TX/TR); for power ON
- Physical interface
- 1 x
- Integrated connection type
- 1 serial RS232/485
- Mounting support
- DIN rail
- Height
- 90 mm
- Width
- 17.5 mm
- Depth
- 58 mm
- IP degree of protection
- IP20
- Ambient air temperature for operation
- 0…45 °C
- Operating altitude
- <= 2000 m
- Relative humidity
- 0…93 %
- Directives
- 2014/53/EU - radio equipment directive
- Unit Type of Package 1
- PCE
- Number of Units in Package 1
- 1
- Package 1 Height
- 7.000 cm
- Package 1 Width
- 13.500 cm
- Package 1 Length
- 18.000 cm
- Package 1 Weight
- 294.000 g
- Unit Type of Package 2
- S03
- Number of Units in Package 2
- 16
- Package 2 Height
- 30.000 cm
- Package 2 Width
- 30.000 cm
- Package 2 Length
- 40.000 cm
- Package 2 Weight
- 5.097 kg
- Warranty (in months)
- 18
- Mounting method
- DRA (DIN-rail adaptor)
- Model
- RS-232
- Voltage type
- DC
- Number of channels
- 16
- Power consumption
- 0.3 W
- Bus system KNX
- No
- Bus system radio frequency
- No
- Bus system Powernet
- No
- Width in number of modular spacings
- 1
- Other bus systems
- Zigbee
- Bus system LON
- No
- Demounting protection
- No
- Radio interface
- Yes
- IR interface
- No
- Provider dependent
- No
- Updateable
- Yes
- Visualization
- Yes
- Web-Server
- No
- Operating voltage
- 24 V
- Degree of protection (IP)
- IP20
- With LED indication
- Yes
- Bus system KNX-RF (Radio Frequency)
- No
- Radio frequency bidirectional
- Yes
- Max. number of devices per channel
- 50
- Bus system KNX Secure
- No
- Bus system KNX Secure-RF (Radio Frequency)
- No
- Country of origin
- Latvia
Standards & Compliance
- HS Code
- 8517.62
Cross References
- EAN 3606482215801
- SAP 1200738898
- Code 83874800
Product Documentation
