Schneider Electric discrete input module X80 - 8 inputs - 200...240 V AC BMXDAI0805

Schneider Electric BMXDAI0805 M340 8 in 220VAC, FTB20x0.

Manufacturer part number (MPN)

BMXDAI0805

EAN / GTIN

3595864081595

Sales unit

pcs

Package quantity

15 pcs

Voltage

220 V AC

Range of product

Modicon X80

Product or component type

Discrete input module

Device application

Industrial application

Discrete input number

8

Discrete input voltage

200...240 V DC for isolated

Input wiring mode

2 or 3 wires

Discrete input current

10.4 mA at 200...240 V AC

Voltage state 1 guaranteed

>= 159 V

Voltage state 0 guaranteed

<= 40 V

Current state 1 guaranteed

>= 4 mA

Discrete input frequency

50 Hz (47…63 Hz); 60 Hz (47…63 Hz)

Input impedance

21000 Ohm

Insulation resistance

> 10 MOhm 500 V DC

AC activation response time

10 ms

AC deactivation response time

20 ms

Sensor power supply

: 170…264 V

Typical current consumption

76 mA; 93.6 mA

Current consumption

<= 126 mA at 3.3 V DC; <= 154.8 mA at 24 V DC

Power dissipation in W

4.73 W

Isolation between channels and bus

1500 V for 1 minute

MTBF reliability

1700000 H

Voltage detection threshold

> 164 V AC sensor OK; < 80 V AC sensor fault

Local signalling

1 LED (green) for module operating (RUN); 1 LED per channel (green) for channel diagnostic; 1 LED (red) for module error (ERR); 1 LED (red) for module I/O

Height

103.7 mm

Width

32 mm

Depth

86 mm

Product weight

0.12 kg

IP degree of protection

IP20

Protective treatment

Standard version

Marking

CE; UKCA; CULus; RCM; EAC

Standards

IEC 61131-2

Directives

2014/35/EU - low voltage directive; 2014/30/EU - electromagnetic compatibility

Dielectric strength

1500 V AC at 50/60 Hz 1 min

Ambient air temperature for operation

0…60 °C

Ambient air temperature for storage

-40…85 °C

Relative humidity

5…95 % at 55 °C without condensation

Operating altitude

0...2000 m; 2000...5000 m with derating

Pollution degree

2

Vibration resistance

3 gn

Shock resistance

30 gn

Number of Units in Package 1

1

Number of Units in Package 2

15

Country of origin

FR

Warranty (in months)

18

Power consumption

4.73 W

Supply voltage DC

3.3–24 V

Voltage type (supply voltage)

AC

Number of digital inputs

8

Digital inputs configurable

No

Digital outputs configurable

No

Input current at signal 1

10.4 mA

Type of voltage (input voltage)

AC

Type of digital output

None

Type of output voltage

AC

Short-circuit protection, outputs available

No

Redundancy

No

Type of electric connection

Plug-in connection

Suitable for safety functions

No

SIL according to IEC 61508

None

Performance level according to EN ISO 13849-1

None

Appendant operation agent (Ex ia)

No

Explosion safety category for gas

None

Explosion safety category for dust

None

HS Code

8538.90
