Schneider Electric Circuit breaker, ComPacT NSX100M AC/DC, 40KA/240VAC, 1 pole, TMD trip unit 30A C10M1TM030

Schneider Electric C10M1TM030 Circuit breaker ComPacT NSX100M AC/DC, 40 kA/ 240 VAC, with thermomagnetic protection TMD 30 A, 1p.

Manufacturer part number (MPN)

C10M1TM030

EAN / GTIN

3606481995759

HS code

8536.90

Sales unit

pcs

Package quantity

15 pcs

Number of poles

1P

Breaking capacity

40 kA

Range

ComPacT

Product name

ComPacT NSX

Device short name

NSX100M

Product or component type

Circuit breaker

Device application

Distribution

Poles description

1P

Protected poles description

1D

[In] rated current

30 A at 40 °C

[Ue] rated operational voltage

277 V AC 50/60 Hz; 250 V DC

Network type

AC; DC

Network frequency

50/60 Hz

Suitability for isolation

Yes conforming to EN/IEC 60947-2

Utilisation category

Category A

Breaking capacity code

M 40 kA 240 V AC

Trip unit name

TM-D

Trip unit technology

Thermal-magnetic

Trip unit protection functions

LI

Control type

Toggle

Circuit breaker mounting mode

Fixed

[Ui] rated insulation voltage

750 V AC 50/60 Hz conforming to IEC 60947-2

[Uimp] rated impulse withstand voltage

8 kV conforming to IEC 60947-2

[Ics] rated service breaking capacity

40 kA at 220/240 V AC 50/60 Hz conforming to IEC 60947-2; 85 kA at 250 V DC conforming to IEC 60947-2

Mechanical durability

20000 cycles

Electrical durability

20000 cycles at 277 V In/2; 10000 cycles at 277 V In

Power dissipation per pole

4.03 W

Mounting support

Backplate

Mounting position

Horizontal and vertical; Flat on the back

Upside connection

Front

Downside connection

Front

Connection pitch

35 mm

Protection type

L : for overload protection (thermal); I : for short-circuit protection (magnetic)

Trip unit rating

30 A at 40 °C

Long-time pick-up adjustment type Ir (thermal protection)

Fixed

[Ir] long-time protection pick-up adjustment range

1 x In

Long-time protection delay adjustment type tr

Fixed

Instantaneous protection pick-up adjustment type Ii

Fixed

[Ii] instantaneous protection pick-up adjustment range

300 A

Earth-leakage protection

Without

Width (W)

35 mm

Height (H)

161 mm

Depth (D)

86 mm

Product weight

0.7 kg

Standards

EN/IEC 60947-2

Overvoltage category

IV

Electrical shock protection class

Class II on front face

Pollution degree

3 conforming to IEC 60664-1

IP degree of protection

IP40 conforming to IEC 60529

IK degree of protection

IK07 conforming to IEC 62262

Ambient air temperature for operation

-25…70 °C

Ambient air temperature for storage

-50…85 °C

Relative humidity

0…95 %

Operating altitude

0...2000 m without derating; 2000 m...5000 m with derating

Warranty (in months)

18

HS Code

8536.90

• EAN 3606481995759
• SAP 1200533365
• Code 82687729
