Schneider Electric MN delay unit, MasterPact MTZ, adjustable time delay 0.5S to 3S, 48/60VDC, 48/60VAC 50/60Hz, spare part LV833680SP
Pricing
Request a quote
We reply within 24 hours
Product Description
Schneider Electric LV833680SP Adjustable Time delay undervoltage coil MNR 48/60VAC/DC Masterpact MTZ.
Technical Specifications
- Manufacturer part number (MPN)
- LV833680SP
- EAN / GTIN
- 3606481173355
- Sales unit
- pcs
- Voltage
- 48/60 V AC
- Range
- MasterPact
- Device short name
- MN delay unit
- Product or component type
- Time delay auxiliary
- Device application
- Control
- Range compatibility
- Masterpact MasterPact MTZ1 circuit breaker; Masterpact MasterPact MTZ2 circuit breaker; Masterpact MasterPact MTZ3 circuit breaker
- Voltage release type
- Instantaneous
- Impulse duration
- 200 ms
- Time delay range
- 0.5...3 s
- [Uc] control circuit voltage
- 48...60 V AC 50/60 Hz; 48...60 V DC
- Threshold tripping voltage
- 0.35...0.7 Un open; 0.85 Un close
- Supply holding power
- 4.5 VA
- Supply inrush power
- 200 VA
- Response time
- 0.5 s; 0.9 s; 1.5 s; 3 s
- Offer type
- Spare part
- Provided equipment
- 1 instruction sheet
- Number of Units in Package 1
- 1
- Number of Units in Package 2
- 30
- Warranty (in months)
- 18
- Rated voltage
- 60 V
- Country of origin
- France
Standards & Compliance
- HS Code
- 8538.90
Cross References
- EAN 3606481173355
- SAP 1200050402
- Code 81878584
