Schneider Electric LV833754 Low-Level Auxiliary Contact, Connected Position, Masterpact MTZ

Schneider Electric LV833754 is a low-level auxiliary contact reporting the connected position of drawout Masterpact MTZ1, MTZ2 and MTZ3 circuit breakers. Configuration is 1 NO/NC. Rated for DC-12 and AC-12 duty at up to 250 V DC and 380 V AC with a minimum load of 2 mA at 15 V.

Manufacturer part number (MPN)

LV833754 EAN / GTIN: 3606480803703 Sales unit: pcs Range: MasterPact Device short name: CE Product or component type: Auxiliary contact Device application: Control Range compatibility: Masterpact MasterPact MTZ1 circuit breaker; Masterpact MasterPact MTZ2 circuit breaker; Masterpact MasterPact MTZ3 circuit breaker Signal contacts composition: 1 NO/NC mounting mode: Drawout Auxiliary contacts type: Low level Auxiliary contacts operation: Connected position [Ie] rated operational current: DC-12: 0.3 A at 250 V DC; DC-12: 0.8 A at 125 V DC; DC-12: 2.5 A at 24/48 V DC; AC-12: 5 A at 24/48 V AC 50/60 Hz; AC-12: 5 A at 240 V AC 50/60 Hz; AC-12: 5 A at 380 V AC 50/60 Hz minimum load: 2 mA at 15 V Unit Type of Package 1: PCE Number of Units in Package 1: 1 Package 1 Height: 1.0 cm Package 1 Width: 5.0 cm Package 1 Length: 5.0 cm Package 1 Weight: 1.012 kg Country of origin: FR Warranty (in months): 18

HS Code

8538.90

• EAN 3606480803703
• SAP 1200050470
• Code 81878869
