Schneider Electric LV850046 IEC 61850 Digital Module for MasterPact MTZ
Pricing
Request a quote
We reply within 24 hours
Product Description
Schneider Electric LV850046 is a digital module enabling IEC 61850 protection and communication on MicroLogic X control units for MasterPact MTZ1, MTZ2 and MTZ3 circuit breakers. It publishes MTZ data over Ethernet via the IEC 61850 MMS protocol using the IFE or EIFE interface alongside Modbus TCP/IP, covering energy metering, electrical measurements and breaker status and control. The module removes the need for an additional gateway when integrating with medium-voltage installations and is configured through EcoStruxure Power Commission.
Technical Specifications
- Manufacturer part number (MPN)
- LV850046
- EAN / GTIN
- 3606489860288
- Sales unit
- pcs
- Range
- MasterPact
- Product or component type
- Application
- Application description
- IEC 61850 for MasterPact MTZ
- Communication network type
- Ethernet conforming to IEC 61850
- Range compatibility
- MasterPact MTZ1 circuit breaker; MasterPact MTZ2 circuit breaker; MasterPact MTZ3 circuit breaker
- Product compatibility
- control unit MicroLogic 2.0 X; control unit MicroLogic 3.0 X; control unit MicroLogic 5.0 X; control unit MicroLogic 6.0 X; control unit MicroLogic 7.0 X; control unit MicroLogic 3.0 Xi; control unit MicroLogic 5.0 Xi; control unit MicroLogic 6.0 Xi
- Service description
- Provides MTZ data over ethernet according to IEC 61850 MMS protocol; Enables IEC 61850 protocol on IFE or EIFE in addition to Modbus TCP/IP protocol; MTZ data are energy metering, electrical measurements and breaker status/control
- Service benefits
- No need of an additional gateway for integration in medium voltage installation
- Energy management
- Diagnostics and maintenance (option)
- Software name
- EcoStruxure Power Commission
- Country of origin
- FR
- Warranty (in months)
- 18
Standards & Compliance
- HS Code
- 8538.90
Cross References
- EAN 3606489860288
- SAP 1200722473
- Code 83837237
