DM over/under frekvensvern MTZ
Pricing
Request a quote
We reply within 24 hours
Product Description
Schneider Electric LV850013 Digital Module, over/underfrekvens protection function for Micrologic X for MTZ.
Technical Specifications
- Manufacturer part number (MPN)
- LV850013
- EAN / GTIN
- 3606489860264
- Sales unit
- pcs
- Range
- MasterPact
- Product or component type
- Application
- Application description
- Under/over frequency ANSI 81
- Range compatibility
- MasterPact MTZ1 circuit breaker; MasterPact MTZ2 circuit breaker; MasterPact MTZ3 circuit breaker
- Product compatibility
- control unit MicroLogic 2.0 X; control unit MicroLogic 3.0 X; control unit MicroLogic 5.0 X; control unit MicroLogic 6.0 X; control unit MicroLogic 7.0 X; control unit MicroLogic 3.0 Xi; control unit MicroLogic 5.0 Xi; control unit MicroLogic 6.0 Xi
- Function of module
- Protection
- Service description
- Circuit breaker trips when the frequency exceeds the settings; Under/over frequency protection monitors frequency
- Service benefits
- Protection of the generators; Enable action to be initiated to safeguard the operation of the installation; Typical actions: load shedding, source changeover, emergency generator starting
- Energy management
- Network management (option)
- Protection type
- Underfrequency ANSI code: 81 (option) ; Overfrequency ANSI code: 81 (option)
- Software name
- EcoStruxure Power Commission
- Country of origin
- FR
- Warranty (in months)
- 18
Standards & Compliance
- HS Code
- 8538.90
Cross References
- EAN 3606489860264
- SAP 1200722472
- Code 83837223
