Fast Time delay for MN 200/250 VAC
Pricing
Request a quote
We reply within 24 hours
Product Description
Schneider Electric 33685 FAST HOURS FOR MN 200/250AC/DC.
Technical Specifications
- Manufacturer part number (MPN)
- 33685
- EAN / GTIN
- 3303430336853
- Sales unit
- pcs
- Package quantity
- 36 pcs
- Device short name
- MN delay unit
- Product or component type
- Time delay relay
- Device application
- Control
- Range compatibility
- Masterpact MasterPact NT; Masterpact MasterPact NW; ComPact ComPact NS630b...1600; ComPact ComPact NS1600b...3200; Masterpact MasterPact NW UL 489; Masterpact MasterPact NT UL 489; Masterpact MasterPact NW DC
- Voltage release type
- Undervoltage release
- [Uc] control circuit voltage
- 200...250 V AC 50/60 Hz; 200...250 V DC
- Impulse duration
- 200 ms
- Time delay range
- 0.25 s
- Threshold tripping voltage
- 0.35...0.7 Un open; 0.85 Un close
- Supply holding power
- 4.5 VA
- Supply inrush power
- 200 VA
- mounting mode
- External mounting
- Response time
- 0.25 s
- Accessory / separate part category
- Spare part for Compact NS630b...1600; Spare part for Compact NS1600b...3200
- Unit Type of Package 1
- PCE
- Number of Units in Package 1
- 1
- Package 1 Height
- 8.5 cm
- Package 1 Width
- 8.0 cm
- Package 1 Length
- 9.0 cm
- Package 1 Weight
- 147.0 g
- Unit Type of Package 2
- S03
- Number of Units in Package 2
- 36
- Package 2 Height
- 30.0 cm
- Package 2 Width
- 30.0 cm
- Package 2 Length
- 40.0 cm
- Package 2 Weight
- 5.73 kg
- Country of origin
- FR
- Warranty (in months)
- 18
- Rated voltage
- 230 V
Standards & Compliance
- HS Code
- 8538.90
Cross References
- EAN 3303430336853
- SAP 1000041244
- Code 8801679
