Schneider Electric GV1G09 TeSys GV2, TeSys D & TeSys U - terminal block - 3P - from the top

Schneider Electric GV1G09 TeSys GV2, TeSys D & TeSys U - terminal block - 3P - from the top is listed under Electrical Components / Busbar Systems. Sales unit: pcs; Package quantity: 70 pcs; Range: Linergy; Product name: FT; Device short name: GV1G; Product or component type: Terminal block.

Manufacturer part number (MPN)

GV1G09

EAN / GTIN

3389110212570

Sales unit

pcs

Package quantity

70 pcs

Range

Linergy

Product name

FT

Device short name

GV1G

Product or component type

Terminal block

Accessory / separate part category

Connection accessory

Poles description

3P

Range compatibility

TeSys GV2; TeSys Deca; TeSys U; TeSys LS1

[Ie] rated operational current

63 A

Mounting location

Top

IP degree of protection

IP20 conforming to IEC 60529

[Ui] rated insulation voltage

690 V conforming to IEC 60947-1

Connections - terminals

Screw clamp terminals 1 cable(s) (4 AWG) - solid; Screw clamp terminals 1 cable(s) 1.5…16 mm² - flexible with cable end; Screw clamp terminals 1 cable(s) 1.5…16 mm² - flexible without cable end; Screw clamp terminals 1 cable(s) 1.5…25 mm² - solid; Screw clamp terminals 2 cable(s) 1.5…4 mm² - flexible with cable end; Screw clamp terminals 2 cable(s) 1.5…6 mm² - solid; Screw clamp terminals 2 cable(s) 1.5…4 mm² - flexible without cable end; Screw clamp terminals 1 cable(s) (4 AWG) - flexible

Tightening torque

1.7 N.m - on screw clamp terminals; 2.2 N.m - on connector

Product weight

0.04 kg

Product certifications

CE; UKCA

Unit Type of Package 1

PCE

Number of Units in Package 1

1

Package 1 Height

4.500 cm

Package 1 Width

6.000 cm

Package 1 Length

7.000 cm

Package 1 Weight

49.000 g

Unit Type of Package 2

S02

Number of Units in Package 2

70

Package 2 Height

15.000 cm

Package 2 Width

30.000 cm

Package 2 Length

40.000 cm

Package 2 Weight

3.706 kg

Unit Type of Package 3

P06

Number of Units in Package 3

1120

Package 3 Height

75.000 cm

Package 3 Width

60.000 cm

Package 3 Length

80.000 cm

Package 3 Weight

69.540 kg

Country of origin

RO

Warranty (in months)

18

Accessory

Yes

Spare part

No

HS Code

8536.50

• EAN 3389110212570
• SAP 1000013721
• Code 8105442
