Resetknapp Black 6 - 16 MM
Pricing
Request a quote
We reply within 24 hours
Product Description
Schneider Electric XB4BA821 — Harmony XB4 22 mm command actuator. Metal or plastic 22 mm cutout push-button, selector or indicator. Black 6-16 mm.
Technical Specifications
- Manufacturer part number (MPN)
- XB4BA821
- EAN / GTIN
- 3389110102048
- Sales unit
- pcs
- Range of product
- Harmony XB4
- Product or component type
- Manual overload reset push-button
- Device short name
- XB4
- Bezel material
- Chromium plated metal
- Fixing collar material
- Zamak
- Head type
- Standard
- Mounting diameter
- 22.5 mm
- Operator profile
- Black flush, unmarked
- Activating distance
- 6…16 mm
- Product weight
- 0.037 kg
- Resistance to high pressure washer
- 7000000 Pa at 55 °C, distance : 0.1 m
- Shape of signaling unit head
- Round
- Operating travel
- 10 mm
- Mechanical durability
- 5000000 cycles
- Protective treatment
- TH
- Ambient air temperature for storage
- -40…70 °C
- Ambient air temperature for operation
- -40…70 °C
- Electrical shock protection class
- Class I conforming to IEC 60536
- IP degree of protection
- IP66 conforming to IEC 60529
- Enclosure Type
- UL type 4X/13
- IK degree of protection
- IK03 conforming to IEC 50102
- Standards
- IEC 60947-5-1; CSA C22.2 No 14; IEC 60947-5-5; IEC 60947-5-4; UL 508; JIS C8201-5-1; IEC 60947-1; JIS C8201-1
- Product certifications
- CSA; DNV; BV; LROS (Lloyds register of shipping); UL listed
- Unit Type of Package 1
- PCE
- Number of Units in Package 1
- 1
- Package 1 Height
- 4.900 cm
- Package 1 Width
- 14.800 cm
- Package 1 Length
- 6.600 cm
- Package 1 Weight
- 368.000 g
- Unit Type of Package 2
- S03
- Number of Units in Package 2
- 64
- Package 2 Height
- 30.000 cm
- Package 2 Width
- 30.000 cm
- Package 2 Length
- 40.000 cm
- Package 2 Weight
- 23.972 kg
- Unit Type of Package 3
- P06
- Number of Units in Package 3
- 512
- Package 3 Height
- 75.000 cm
- Package 3 Width
- 80.000 cm
- Package 3 Length
- 60.000 cm
- Package 3 Weight
- 199.776 kg
- Country of origin
- FR
- Warranty (in months)
- 18
- Hole diameter
- 22.5 mm
- Colour button
- Black/white/red
- Suitable for lighting
- No
- Number of command positions
- 1
- Spring-return
- Yes
- Labelled
- No
- Type of button
- Flat
- Colour front ring
- Chrome
- Degree of protection (IP), front side
- IP66
- With protective cover
- No
- Material front ring
- Metal
- With front ring
- Yes
- Construction type lens
- Round
- Switching function latching
- No
Standards & Compliance
- HS Code
- 8538.90
Cross References
- EAN 3389110102048
- SAP 1000071421
- Code 8765364
Product Documentation
