Schneider Electric NSYBCE12 Spacial SF Brush Gasket for Cable Entry, 1200 mm

Schneider Electric NSYBCE12 is a set of two brush gaskets for the Spacial SF enclosure range, designed to seal cable gland plates while allowing multiple cable entries. Nominal length 1200 mm (real 505 mm), height 40 mm, depth 25 mm, clip-fixed to the cable gland plate.

Manufacturer part number (MPN)

NSYBCE12

EAN / GTIN

3606485130019

Sales unit

pcs

Range

PanelSeT

Product or component type

Brush gasket

Accessory / separate part category

Cable management accessory

Device application

Multi-purpose

Range compatibility

PanelSeT SF SF suitable enclosure

Device composition

2 gasket

Quantity per set

Set of 1

Mounting support

Cable gland plate

cable entry

1 or 2 entries

Fixing mode

Clipped

Height

40 mm

Width

Nominal: 1200 mm; Real: 505 mm

Depth

25 mm

Unit Type of Package 1

PCE

Number of Units in Package 1

1

Package 1 Height

9.000 cm

Package 1 Width

7.000 cm

Package 1 Length

74.000 cm

Package 1 Weight

568.000 g

Unit Type of Package 2

P12

Number of Units in Package 2

100

Package 2 Height

90.000 cm

Package 2 Width

80.000 cm

Package 2 Length

120.000 cm

Package 2 Weight

140.528 kg

Country of origin

FR

Warranty (in months)

18

Model

Brush

Surface protection

Untreated

Pre-stamping

No

Type

Straight

Thread type

None

Material

Plastic

HS Code

3926.90

• EAN 3606485130019
• SAP 1000317453
• Code 81014769
