WALL-Mount Cabinet WITH WINDOW. 8X8X3
Pricing
Request a quote
We reply within 24 hours
Product Description
Schneider Electric NSYS3D8830T Wall-mount cabinet With Window. 8X8X3.
Technical Specifications
- Manufacturer part number (MPN)
- NSYS3D8830T
- EAN / GTIN
- 3606480158834
- Sales unit
- pcs
- Range
- PanelSeT
- Product name
- PanelSeT S3D
- Application
- Multi-purpose
- Category
- Compact enclosure
- Enclosure nominal height
- 800 mm
- Enclosure nominal width
- 800 mm
- Enclosure nominal depth
- 300 mm
- Door type
- Glazed
- Mounting plate description
- Without mounting plate
- Type of gland plate
- Standard
- Installation accessory type
- Wall-mounting
- Device composition
- 1 body; 2 cable gland plate; 1 door; 1 lock
- body type
- Single piece body; Gutter-shaped front rail double sheet thickness
- Number of doors
- Front face: 1 door(s)
- Door opening side
- Reversible (120 °)
- Lock type
- 3 points lock, 3 mm double-bar
- Accessibility for operation
- Front
- Removable parts
- Door by hinges; Cable gland plate by screws
- Material
- Body: steel; Door: steel and security glass
- Surface finish
- Epoxy-polyester powder
- Colour
- Grey (RAL 7035)
- Standards
- IEC 62208; UL; CUL
- Product certifications
- BV; UL; cUL; GL; DNV
- Product weight
- 31 kg
- Electromagnetic compatibility
- Electromagnetic field immunity test
- NEMA degree of protection
- NEMA 4X/13
- IK degree of protection
- IK08 conforming to IEC 62262
- IP degree of protection
- IP66 conforming to IEC 60529
- Unit Type of Package 1
- PCE
- Number of Units in Package 1
- 1
- Package 1 Height
- 35.500 cm
- Package 1 Width
- 81.500 cm
- Package 1 Length
- 81.500 cm
- Package 1 Weight
- 28.166 kg
- Unit Type of Package 2
- P12
- Number of Units in Package 2
- 6
- Package 2 Height
- 178.000 cm
- Package 2 Width
- 80.000 cm
- Package 2 Length
- 120.000 cm
- Package 2 Weight
- 182.000 kg
- Country of origin
- FR
- Warranty (in months)
- 18
- Width
- 800 mm
- Height
- 800 mm
- Depth
- 300 mm
- RAL-number
- 7035
- Number of locks
- 1
- Impact strength
- IK08
- Degree of protection (IP)
- IP66
- Suitable for outdoor set-up
- No
- Connectable
- No
- Wall fastening possible
- Yes
- Surface finishing
- Powder coating
- Max. permitted load of the enclosure according to IEC 62208
- 250 N
Standards & Compliance
- HS Code
- 9403.20
Cross References
- EAN 3606480158834
- SAP 1000089659
- Code 8582012
Product Documentation
More from Schneider Electric
Schneider Electric
DOUBLE PUSH BUTTON for LIGHT Black KN UMRK (ZB5AW7A1720)
Schneider Electric
Schneider Electric Circuit breaker, ComPacT NSXm 160B, 25KA/415VAC, 4 poles, MicroLogic 4.1 trip unit 100A, lugs/busbars C11B44V100B
Schneider Electric
Schneider Electric Contactor, TeSys Deca, 3P(3NO), AC-3/3E, <=440V, 25A, 60V DC coil, snap-in terminals LC1D25AND
Schneider Electric
PUSH BUTTON CAP, "stop"
ZBA434
Schneider Electric
Schneider Electric right angle terminal extensions, ComPact NSX 400/630, set of 3 parts LV432484
Schneider Electric
Modular blank plate (NSYMPC406)
Schneider Electric
Illuminated Push Button pressure/pressure yellow (ZB5AH083)
Schneider Electric
Sign 8X27, FOR ZBZ-32/34 (ZBY0102)
