Schneider Electric PLS box, polyester rear, opaque PC cover IP65 36X54X23CM NSYPLSC3654AG
Pricing
Request a quote
We reply within 24 hours
Product Description
Schneider Electric NSYPLSC3654AG sealed PC PLS 7035 box36x54x23.
Technical Specifications
- Manufacturer part number (MPN)
- NSYPLSC3654AG EAN / GTIN: 3606480777189 Sales unit: pcs Package quantity: 45 pcs Range: PanelSeT Product name: PanelSeT PLS Device short name: PLS Enclosure type: Multi-purpose Category: Insulating modular box Nominal height: 360 mm Nominal width: 540 mm Nominal depth: 230 mm Enclosure mounting: Wall mounted Device composition: 1 cover: on enclosure; 1 rear part: on enclosure; locking screws Body type: One piece moulded Type of front cover: High plain cover Lock type: Slot screw Removable parts: Cover locking screw material: Cover: polycarbonate; Rear: polyester reinforced with fibreglass Colour: Body: grey (RAL 7035) Standards: NEMA 4X; NEMA classification 13; IEC 62208 Product certifications: UL Electrical insulation class: Class II IP degree of protection: IP66 conforming to IEC 60529 IK degree of protection: IK09 conforming to IEC 62262 Fire resistance: 960 °C conforming to IEC 62208 Ambient air temperature for storage: -30…70 °C Number of Units in Package 1: 1 Number of Units in Package 2: 45 Country of origin: ES Warranty (in months): 18 Width: 540 mm Height: 360 mm Depth: 230 mm RAL-number: 7035 With mounting plate: No material quality: Polyester Impact strength: IK09 Degree of protection (IP): IP66
Standards & Compliance
- HS Code
- 9403.70
Cross References
- EAN 3606480777189
- SAP 1200013081
- Code 81383411
Product Documentation
