Product Description
Schneider Electric LVS04922 is a Form 2 side barrier for the lateral vertical busbar in PrismaSeT P enclosures, providing internal separation between the busbar and functional units. The 1926 × 110 mm insulating panel suits a 650 × 400 mm cubicle over 36 vertical 50 mm modules and is finished in matt white (RAL 9003). Typical use is compartment segregation in Schneider PrismaSeT P switchboards.
Technical Specifications
- Manufacturer part number (MPN)
- LVS04922
- EAN / GTIN
- 3606481880314
- Sales unit
- pcs
- Range
- PrismaSeT
- Range of product
- PrismaSeT P
- Product or component type
- Barrier
- Accessory / separate part category
- Insulation accessory
- Range compatibility
- PrismaSeT PrismaSeT P framework
- Cubicle partitioning form
- Form 2
- Barrier position
- Side
- installation description
- Cubicle - width 650 mm, depth 400 mm
- Installed device
- Vertical lateral busbar
- Number of vertical modules [50 mm]
- 36
- Quantity per set
- Set of 1
- Height
- 1926 mm
- Width
- 110 mm
- Surface finish
- Matt; Textured
- Protective treatment
- Electrophoresis treatment and hot-polymerised polyester epoxy powder
- Colour
- White (RAL 9003)
- Product weight
- 6.04 kg
- Unit Type of Package 1
- PCE
- Number of Units in Package 1
- 1
- Package 1 Height
- 3.700 cm
- Package 1 Width
- 12.800 cm
- Package 1 Length
- 181.000 cm
- Package 1 Weight
- 6.142 kg
- Unit Type of Package 2
- PAL
- Number of Units in Package 2
- 48
- Package 2 Height
- 36.000 cm
- Package 2 Width
- 120.000 cm
- Package 2 Length
- 202.000 cm
- Package 2 Weight
- 320.000 kg
- Country of origin
- FR
- Warranty (in months)
- 18
- Suitable for enclosure building width
- 650 mm
- Suitable for enclosure building depth
- 400 mm
- Surface finishing
- Powder coating
- RAL-number
- 9003
- With cable entry
- No
- With lock
- No
- Construction type
- Individual part
- For internal separation form 2a
- No
- For internal separation form 2b
- No
- For internal separation form 3a
- No
- For internal separation form 3b
- No
- For internal separation form 4a
- No
- For internal separation form 4b
- No
Standards & Compliance
- HS Code
- 7326.90
Cross References
- EAN 3606481880314
- SAP 1200547180
- Code 82879062
