Schneider Electric Linergy Evolution LGYE Splice Plate Set, 2500 A

Set of twelve splice plates with contact washers and M8 nuts for jointing Linergy Evolution LGYE and LGY busbars in PrismaSeT P cubicles up to 2500 A. Two-stud fixing per joint supports rated operational currents of 1600, 2000 and 2500 A within a single distribution frame. Supplied in packs of ten sets for panel-builder use.

Manufacturer part number (MPN)

LVS04768

EAN / GTIN

3606481869104

Sales unit

pcs

Package quantity

10 pcs

Rated current

2500 A

Range

Linergy

Range of product

Linergy

Product or component type

Mounting hardware

Product name

Linergy LGY

Accessory / separate part category

Fixing accessory

Range compatibility

Linergy Linergy LGYE busbar; Linergy Linergy LGY busbar; PrismaSeT PrismaSeT P cubicle

Provided equipment

1 contact washer; 1 nut

Cubicle-device connection

Busbar; Linergy busbar

[Ie] rated operational current

1600 A; 2000 A; 2500 A

installation description

Cubicle

Number of studs

2 stud

ISO thread

M8

Quantity per set

Set of 12

Length

37 mm

Colour

Natural

Product weight

0.9 kg

Number of Units in Package 1

1

Number of Units in Package 2

10

Number of Units in Package 3

80

Country of origin

FR

Warranty (in months)

18

Accessory

Yes

Spare part

Yes

HS Code

7318.15
