NG125L/D 32-4 Modular Power Switch
Pricing
Request a quote
We reply within 24 hours
Product Description
Schneider Electric 18861 NG125L/D 32-4 Modular power switch
Technical Specifications
- Manufacturer part number (MPN)
- 18861
- EAN / GTIN
- 3303430188612
- Sales unit
- pcs
- Package quantity
- 12 pcs
- Power loss
- 3.8 W
- Built-in depth
- 47 mm
- Release characteristic
- D
- Number of poles (total)
- 4
- Number of protected poles
- 4
- Rated current
- 32 A
- Rated voltage
- 415 V
- Rated insulation voltage Ui
- 690 V
- Rated impulse withstand voltage Uimp
- 8 kV
- Frequency
- 50–60 Hz
- Concurrently switching neutral conductor
- Yes
- Overvoltage category
- 4
- Pollution degree
- 3
- Additional equipment possible
- Yes
- Width in number of modular spacings
- 6
- Degree of protection (IP)
- IP20
- Ambient temperature during operating
- -30–70 °C
- Connectable conductor cross section multi-wired
- 1–35 mm²
- Connectable conductor cross section solid-core
- 1.5–50 mm²
- Explosion-proof
- No
- Flush-mounted installation
- No
- Country of origin
- France
Standards & Compliance
- HS Code
- 8536.20
Cross References
- EAN 3303430188612
- SAP 1000034550
- Code 8253988
Product Documentation
More from Schneider Electric
Schneider Electric
Schneider Electric APC Replacement Battery Cartridge, Valve regulated lead–acid battery, 7AH, 12VDC, 2-Year warranty RBC2
Schneider Electric
SRT 19" Raik Kit UPS 5-20KVA
SRTGRK1
Schneider Electric
Schneider Electric A9F92425 ACTI9 IC60L Miniature Circuit Breaker 4P 25 A, Curve Z
Schneider Electric
Schneider Electric Trip unit MicroLogic Vigi 7.2E ALUMINIUM, ComPacT NSX100-250, 4P, basic protections, earth leakage alarm, energy meter, 40A C1047A040
Schneider Electric
Schneider Electric Contactor, TeSys Deca, 3P(3NO), AC-3/3E, <=440V, 18A, 12V AC 50/60Hz coil, snap-in terminals LC1D18AJ7
Schneider Electric
Schneider Electric transfer switch, TransferPacT Active automatic, 80A, 400V, 3P, LCD,frame 100A TA10D3L0804TPE
Schneider Electric
Schneider Electric Circuit breaker, ComPacT NSXm 160B, 25KA/415VAC, 3 poles, MicroLogic 4.1 trip unit 100A, lugs/busbars C11B34V100B
Schneider Electric
Schneider Electric Universal cross rails, PanelSeT SFN, PanelSeT SF, PanelSeT SM, H40 W700MM, 1 row, set of 2 NSYSUCR4070
Technical guides
Catalogue entry last verified: 2026-09-30. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy 18861?
- 18861 can be ordered from cballast.com as a Schneider Electric catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Schneider Electric product?
- The manufacturer part number is 18861.
- What is the HS code for 18861?
- The customs tariff (HS) code for 18861 is 8536.20.
- Who manufactures 18861?
- 18861 is a Schneider Electric product in the Electrical Components range.
- Is a datasheet available for 18861?
- Yes — the 18861 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for 18861?
- The minimum order quantity is 1.
- Is 18861 available?
- Yes — 18861 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
