NG125L/C 10-4 Modular Power Switch
Pricing
Request a quote
We reply within 24 hours
Product Description
Schneider Electric 18810 NG125L/C 10-4 Modular power switch
Technical Specifications
- Manufacturer part number (MPN)
- 18810
- EAN / GTIN
- 3303430188100
- Sales unit
- pcs
- Package quantity
- 12 pcs
- Power loss
- 1.7 W
- Built-in depth
- 47 mm
- Release characteristic
- C
- Number of poles (total)
- 4
- Number of protected poles
- 4
- Rated current
- 10 A
- Rated voltage
- 415 V
- Rated insulation voltage Ui
- 690 V
- Rated impulse withstand voltage Uimp
- 8 kV
- Frequency
- 50–60 Hz
- Concurrently switching neutral conductor
- Yes
- Overvoltage category
- 4
- Pollution degree
- 3
- Additional equipment possible
- Yes
- Width in number of modular spacings
- 6
- Degree of protection (IP)
- IP20
- Ambient temperature during operating
- -30–70 °C
- Connectable conductor cross section multi-wired
- 1–35 mm²
- Connectable conductor cross section solid-core
- 1.5–50 mm²
- Explosion-proof
- No
- Flush-mounted installation
- No
- Country of origin
- France
Standards & Compliance
- HS Code
- 8536.20
Cross References
- EAN 3303430188100
- SAP 1000036187
- Code 8515256
Product Documentation
More from Schneider Electric
Schneider Electric
Schneider Electric Contactor, TeSys Deca, 3P(3NO), AC-3/3E, <=440V, 12A, 115V AC 50/60Hz coil, screw clamp terminals LC1D12FE7
Schneider Electric
Schneider Electric Illuminated push button, Harmony XB5, white, 30mm, universal LED, 1NO + 1NC, 24V AC DC XB5FW31B5
Schneider Electric
Plinth 7035 f PLM 200X556X352
NSYZM283G
Schneider Electric
Schneider Electric Circuit breaker, ComPacT NSX400F DC, 36KA/750VDC, 3 poles, TM-DC trip unit 320A C40F3TM320D
Schneider Electric
Push Button Cap flush black (ZBAF2935)
Schneider Electric
Schneider Electric Advanced control unit, TeSys U, 3-12A, 3P motors, protection & diagnostic, class 20, coil 24V AC LUCD12B
Schneider Electric
Schneider Electric Circuit breaker, ComPacT NSXm 160H, 70KA/415VAC, 4 poles, MicroLogic 4.1 trip unit 100A, EverLink lugs C11H44V100L
Schneider Electric
Schneider Electric Interlocking cables, MasterPact MTZ2/MTZ3, 2 cables, 6M, spare part LV833207SP
Technical guides
Catalogue entry last verified: 2026-09-30. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy 18810?
- 18810 can be ordered from cballast.com as a Schneider Electric catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Schneider Electric product?
- The manufacturer part number is 18810.
- What is the HS code for 18810?
- The customs tariff (HS) code for 18810 is 8536.20.
- Who manufactures 18810?
- 18810 is a Schneider Electric product in the Electrical Components range.
- Is a datasheet available for 18810?
- Yes — the 18810 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for 18810?
- The minimum order quantity is 1.
- Is 18810 available?
- Yes — 18810 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
