Schneider Electric STD - SAE - remote control dimmer - 400 W CCTDD20002
Pricing
Request a quote
We reply within 24 hours
Product Description
Schneider Electric CCTDD20002 Dimmer f/el.transformer STD400RC SAE.
Technical Specifications
- Manufacturer part number (MPN)
- CCTDD20002
- EAN / GTIN
- 3606480160653
- HS code
- 8536.90
- Sales unit
- pcs
- Package quantity
- 24 pcs
- range of product
- Acti9
- Product name
- Acti9 STD
- Product or component type
- Remote control dimmer
- Device short name
- STD
- Product compatibility
- Power regulators designed
- Function available
- Automatic load type detection
- Device application
- Building
- Load type
- 230 V AC halogen lamp: 40...400 W; 230 V AC incandescent lamp: 40...400 W; low voltage halogen lamp with electronic transformer: 40...400 W; motor: 40...200 W; low voltage halogen lamp with conventional transformer: 40...400 W; low voltage halogen lamp with toroidal transformer: 40...300 W
- Control type
- Local control: push-button; Remote control: push-button
- Power consumption in VA
- 0.8 VA
- Thermal losses
- 3 W
- Input type
- Push-button 4 allows control up to 20 dimmers
- [Ue] rated operational voltage
- 230 V AC +/- 10 % at 50 Hz
- Input voltage
- 12...30 V AC/DC
- Protection type
- Electronic over temperature protection; Electronic overload protection; Single shot thermal fuse; Electronic overvoltage protection
- Mounting support
- DIN rail
- 9 mm pitches
- 4
- Connected auxiliaries
- Maximum 25 auxiliary push-buttons without light indication, distance : < 50 m; Maximum 5 auxiliary push-buttons with light indication, distance : < 50 m
- Connections - terminals
- Screw terminals, 2 cable(s) 4 mm² top; Screw terminals, 5 cable(s) 2.5 mm² bottom
- Maximum cable distance between devices
- 50 m
- Height
- 85 mm
- Width
- 36 mm
- Depth
- 62 mm
- Product weight
- 80 g
- IP degree of protection
- IP20
- Standards
- EN 60669-2-1
- Directives
- 73/23/EEC - low voltage directive; 89/336/EEC - electromagnetic compatibility
- Ambient air temperature for operation
- 0…70 °C
- Ambient air temperature for storage
- 0…60 °C
- Number of Units in Package 1
- 1
- Number of Units in Package 2
- 24
- Warranty (in months)
- 18
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 3606480160653
- SAP 1000516370
- Code 8632172
Product Documentation
