Schneider Acti9 ITA 1-Channel Weekly/Yearly Time Switch 230 V AC

Schneider Electric Acti9 ITA single-channel programmable time switch with 24-hour, 7-day and yearly cycles, 230 V AC 50/60 Hz. Backlit LCD display, 16 A switching at 250 V AC, four DIN modules wide. Lithium backup preserves time and program for up to 10 years.

Manufacturer part number (MPN)

CCT15910 EAN / GTIN: 3606480625176 Sales unit: pcs Package quantity: 18 pcs Voltage: 230 V AC range of product: Acti9 Product name: Acti9 ITA Device short name: ITA Product or component type: Yearly programmable time switch Device application: Building battery type: Lithium Number of channels: 1 User language: Romanian; English; Danish; German; Spanish; Italian; Swedish; French; Norwegian; Dutch; Czech; Hungarian; Polish; Finnish; Portuguese Colour tint: White (RAL 9003) Maximum switching current: 16 A - 250 V AC pf = 1; 6 A - 250 V AC pf = 0.6 [Ue] rated operational voltage: 230 V AC at 50/60 Hz Accuracy: +/- 0.5 s/day 20 °C Cycle duration: 24 hours + 7 days + year Maximum number of switchings: 300 minimum interval duration: 1 s Function available: Manual or software programming; Cycle programming; Time synchronisation via antenna possible; External input for override; Automatic winter/summer time changeover; Pulse programming Display type: Backlit LCD Battery life: 10 year(s) Backup time: 10 years time and program saving Type of setting: Absence for holidays function; PIN code Connections - terminals: screw terminals Mounting support: DIN rail 9 mm pitches: 4 Width: 35.8 mm Height: 90 mm Depth: 63 mm Function: Pulse programming Absence for holidays: Yes Time changeover: Automatic Updated by: DCF77; GPS Compatibility code: ITA Market segment: Small commercial Ambient air temperature for operation: -30…55 °C IP degree of protection: IP20 Number of Units in Package 1: 1 Number of Units in Package 2: 18 Warranty (in months): 18 Shortest switching time channel 1: 1 s Mounting method: DIN rail Voltage type (supply voltage): AC Autonomy in years: 10 Contact type: Change-over contact Number of memory locations: 300 Nominal switching current at 250 V AC: 16 A Degree of protection (IP): IP20 Width in number of modular spacings: 2 Country of origin: Germany

HS Code

9107.00

• EAN 3606480625176
• SAP 1000516197
• Code 8393243
