Main pole 12A (VZ02)
Pricing
Request a quote
We reply within 24 hours
Product Description
Schneider Electric VZ02 Main pole 12A.
Technical Specifications
- Manufacturer part number (MPN)
- VZ02
- EAN / GTIN
- 3389110448856
- Sales unit
- pcs
- Package quantity
- 69 pcs
- Range
- TeSys
- Device short name
- VZ
- Product or component type
- Additional pole
- Performance level
- High performance
- Poles description
- 1P
- Contacts type and composition
- 1 NO
- Product compatibility
- V02
- Range compatibility
- TeSys TeSys VARIO switch disconnector
- Network type
- DC; AC
- Network frequency
- 50/60 Hz
- Suitability for isolation
- Yes
- Mounting location
- Left; Right
- [Ue] rated operational voltage
- 690 V AC 50/60 Hz
- [Uimp] rated impulse withstand voltage
- 8 kV
- [Ith] conventional free air thermal current
- 12 A
- [Ithe] conventional enclosed thermal current
- 10 A
- Mechanical durability
- 100000 cycles
- Electrical durability
- 100000 cycles AC-21; 30000 cycles DC-1...5
- Connections - terminals
- Power circuit: screw clamp terminals6 mm² - flexible - with cable end; Power circuit: screw clamp terminals10 mm² - solid
- Tightening torque
- Power circuit: 2.1 N.m - on screw clamp terminals
- Height
- 74 mm
- Width
- 16 mm
- Depth
- 35 mm
- Product weight
- 0.05 kg
- Standards
- IEC 60947-3
- Product certifications
- CSA; UL; GL; UKCA
- Protective treatment
- TC
- IP degree of protection
- IP20 conforming to IEC 60529
- Mechanical robustness
- Vibrations 10...150 Hz (1 gn) conforming to IEC 60068-2-6; Shocks 11 ms (30 Gn) conforming to IEC 60068-2-27
- Ambient air temperature for operation
- -20…50 °C
- Fire resistance
- 960 °C conforming to IEC 60695-2-1
- Number of Units in Package 1
- 1
- Number of Units in Package 2
- 69
- Country of origin
- CZ
- Warranty (in months)
- 18
Standards & Compliance
- HS Code
- 8538.90
Cross References
- EAN 3389110448856
- SAP 1000019608
- Code 8164031
