Rittal
CMC III Analogue Airflow Sensor
Part number7030140EAN / GTIN4028177659520HS code8531.90
Enclosures
Enclosure Accessories
MOQ:1
Pricing
Request a quote
We reply within 24 hours
Product Description
Rittal 7030140 CMC III analogue airflow sensor for monitoring air flow in enclosures and compartments; WHD 110 × 30 × 40 mm.
Technical Specifications
- Manufacturer part number (MPN)
- 7030140
- EAN / GTIN
- 4028177659520
- Sales unit
- pcs
- Model designation
- DK 7030.140
- Product type
- CMC III Sensors
- Version
- Analog airflow sensor
- Applications
- Enclosure monitoring in IT, industry and facility management; Monitoring enclosures, rooms and containers in the field of IT.
- Material
- Plastic; Front: Smooth; Housing: Textured
- Color
- Front: RAL 9005; Housing: RAL 7035
- Supply includes
- Sensor; Mounting panel; Assembly components; External airflow sensor including assembly components
- Connection to the CAN bus
- Direct
- Interfaces
- 2 x RJ45 CAN bus; Terminal
- Quantity of participants per IoT interface (max.)
- 10
- Quantity of participants PU (max.)
- 10
- Number subscribers per PDU note
- Max. 5 pcs for power supply via PoE
- Measuring technique
- Differential Temperature Measurement
- Dimensions
- Width: 110 mm; Height: 30 mm; Depth: 40 mm
- Operating temperature range
- 0 °C...55 °C; 32 °F...131 °F
- Ambient humidity (non- condensing)
- 5...95 %
- Packaging unit
- 1 pc(s).
- Net weight
- 0.53 kg
- Gross weight
- 0.536 kg
- PCF/VE (cradle-to-gate)
- 1.6 kg CO2 eq (Cat B)
- Information regarding the PCF class
- Category B: PCF value (cradle-to-gate) calculated approximately on the basis of the product weight and self-declared
- Customs tariff number
- 85319000
- ETIM 9
- EC002627
- ECLASS 8.0
- 27189253
- Country of origin
- Germany
Standards & Compliance
- HS Code
- 8531.90
Cross References
- EAN 4028177659520
- SAP 1000791776
- Code 81403783
Product Documentation
Document preview: Rittal 7030140 — Data Sheet (OEM)
