Phoenix Contact PLC-RSC-24DC/21AU PLC-Interface Relay Module 24 V DC Gold Contact

Phoenix Contact PLC-RSC-24DC/21AU is a PLC-INTERFACE relay module comprising a PLC-BSC screw-connection base and a pluggable miniature relay with multilayer gold contacts. The polarised, monostable relay carries one change-over contact suitable for low-level signal switching at 9 mA nominal current, energised from 18.5 to 33.6 V DC. An LED indicator confirms coil status and the assembly is IP20 with a 6.2 mm-wide housing. Manufacturer order number 2966265; supplied in packs of 10.

Manufacturer part number (MPN)

PLC-RSC- 24DC/21AU

EAN / GTIN

4017918131036

Sales unit

pcs

Package quantity

10 pcs

Product type

Relay Module

Manufacturer order number

2966265

Type of electric connection

Screw connection

With detachable clamps

No

Nominal current

0.009 A

Rated control supply voltage AC 50 Hz

24 V

Rated control supply voltage AC 60 Hz

24 V

Rated control supply voltage DC

18.5–33.6 V

Voltage type for actuating

DC

Drive, polarization

Polarized

Drive, switching attitude

Mono stable

Number of contacts as change-over contact

1

With forced-guided contacts

No

Type of switch contact

Single contact

Complete with socket

Yes

With LED indication

Yes

Material of contact surface

Gold

Degree of protection (IP)

IP20

Width

6.2 mm

Height

80 mm

Depth

94 mm

Country of origin

Germany

HS Code

8536.49
