Phoenix Contact MTK-P/P with BLOCK BU Knife-Disconnect Terminal Block 0.2-2.5 mm Blue
Pricing
Request a quote
We reply within 24 hours
Product Description
Phoenix Contact MTK-P/P With BLOCK BU is a screw-connection knife-disconnect terminal block in blue for conductors from 0.2 to 4 mm² solid and 0.2 to 1.5 mm² stranded. It is rated 16 A at 400 V with two clamp positions across a single level and an integrated test socket. The block measures 5.15 mm wide, 46.35 mm high and 38.7 mm deep, operates from -60 to 105 °C and is supplied in packs of 50.
Technical Specifications
- Manufacturer part number (MPN)
- MTK-P/P M/BLOCK BU
- EAN / GTIN
- 4017918229160
- Sales unit
- pcs
- Package quantity
- 50 pcs
- Connectable conductor cross section solid-core
- 0.2–4 mm²
- Connectable conductor cross section multi-wired
- 0.2–1.5 mm²
- Rated current In
- 16 A
- Rated voltage
- 400 V
- Type of electrical connection 1
- Screw connection
- Type of electrical connection 2
- Screw connection
- Number of levels
- 1
- Number of clamp positions per level
- 2
- Internally connected stages
- No
- Operating temperature
- -60–105 °C
- Width
- 5.15 mm
- Width/grid dimension
- 5.2 mm
- Height
- 46.35 mm
- Depth
- 38.7 mm
- Closing plate required
- Yes
- Colour
- Blue
- With integrated test socket
- Yes
- Length
- 46 mm
- Country of origin
- Germany
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 4017918229160
- SAP 1000083152
- Code 8798513
Product Documentation
