OBO Bettermann
5099617 OBO Module V20-C/0-500V
Part numberV20-C 0-550EAN / GTIN4012195396970HS code8536.30
Switchgear & Protection
Surge Protectors
MOQ:1
Pricing
Request a quote
We reply within 24 hours
Product Description
OBO Bettermann V20-C 0-550 Surge protection device-pluggable top section V20-C/0-550V.
Technical Specifications
- Manufacturer part number (MPN)
- V20-C 0-550
- EAN / GTIN
- 4012195396970
- Sales unit
- pcs
- Package quantity
- 32 pcs
- System configuration
- TN
- System configuration DC
- No
- System configuration IT
- Yes
- System configuration TN
- Yes
- System configuration TN-C
- Yes
- System configuration TT
- Yes
- System configuration other
- Yes
- Number of conductors (without earthing)
- 1
- Nominal discharge surge current (8/20)
- 20 kA
- Max. discharge surge current (8/20)
- 40 kA
- Nominal voltage AC
- 550 V
- Nominal voltage DC
- 230 V
- Max. continuous voltage AC
- 550 V
- Max. continuous voltage DC
- 745 V
- Max. PV-voltage
- 745 V
- Voltage protection level
- 2.4 kV
- Voltage protection level L-N
- 20 kV
- Voltage protection level N-PE
- 20 kV
- Short-circuit breaking capacity (Isccr)
- 20 kA
- Integrated backup fuse
- Yes
- Mounting method
- On basic element
- Construction size
- 1 modular spacing
- Max. conductor cross section solid (solid, stranded)
- 35 mm²
- Max. conductor cross section flexible (fine-strand)
- 35 mm²
- With remote signalling contact
- No
- Signalling at the device
- None
- Category type 2
- Yes
- Degree of protection (IP)
- IP20
- Country of origin
- Hungary
Standards & Compliance
- HS Code
- 8536.30
Cross References
- EAN 4012195396970
- SAP 1000035396
- Code 8263621
Product Documentation
Document preview: 5099617 OBO Module V20-C/0-500V (V20-C 0-550) — Specification sheet
