nVent HOFFMAN EFP220-115R5 Filter Fan Air flow 110 M3/h, 115V, Outdoor, IP55
Pricing
Request a quote
We reply within 24 hours
Product Description
nVent HOFFMAN EFP220-115R5 — Filter Fan Air flow 110 m3/h, 115V, Outdoor, IP55. This outdoor filter fan, EEP, is easy to install, downtime is avoided, and ideal in indoor and outdoor environments.
Technical Specifications
- Manufacturer part number (MPN)
- EFP220-115R5
- EAN / GTIN
- 8713574132986
- Sales unit
- pcs
- Air flow
- 110 m³/h
- EL-number (NO)
- 4913324
- Airflow volume, with filter
- 55/56m³/h
- Aiflow volume, without filter
- 100/110m³/h
- Nominal voltage
- 115 V
- Height
- 202 mm (7.95 in)
- Width
- 202 mm (7.95 in)
- Depth
- 93 mm (3.66 in)
- Cutout size
- 6.97 x 6.97in / 177 x 177mm
- Nominal current
- 0.24/0.23A
- Protection rating
- IP55; NEMA Type 12
- Material
- Thermoplastic
- Finish
- Smooth
- Color
- Light Gray
- Color code
- RAL 7035
- Frequency
- 50/60 HzHz
- Connection type
- Terminal Strip
- Noise level
- 40dB(A)
- Weight
- 1.05 kg (2.32 lb)
- UPC
- 783510476229
- Standard packaging quantity
- 1
- Packing quantity
- 1
- Mounting method
- Snap mounting
- Colour
- Grey
- RAL-number
- 7.04
- Voltage type
- AC
- Suitable for 19 inch rack mounting
- No
- Number of fans
- 1
- EMC-version
- No
- Degree of protection (IP)
- IP55
- With filter
- Yes
- Rated power
- 20 W
- Roof ventilator
- No
- Built as slide-in ventilator
- Yes
- Volume flow, freeblowing
- 110 m³/h
- Air circulator
- No
- Suitable for wall built-in
- Yes
- Operating voltage AC 60 Hz
- 103.5–126.5 V
- Country of origin
- Germany
Standards & Compliance
- HS Code
- 8414.90
Cross References
- EAN 8713574132986
- SAP 1000350075
- Code 81289471
Product Documentation
More from nVent HOFFMAN
nVent HOFFMAN
nVent HOFFMAN LHC528 Locking System for Lift Handle, LHC, 37X23X41MM, Zinc Plt, Steel, Double-bit 3mm
nVent HOFFMAN
nVent HOFFMAN ADO202S Door Stop Wall Mounted Enclosures, ADO, 16X164X3MM, Stainless Steel 316
nVent HOFFMAN
nVent HOFFMAN LPS10USA Socket with fuse USA, DIN rail mounting, plastic UL approved
nVent HOFFMAN
nVent HOFFMAN LPS10 Socket with fuse, DIN rail mounting, plastic UL approved
nVent HOFFMAN
nVent HOFFMAN AMI06050 Bakelite Insulated Mounting Panel 600×500 mm
nVent HOFFMAN
nVent HOFFMAN LF430 Leveling Feet, LF, 67X48X48MM, Mild Steel/Plastic
nVent HOFFMAN
nVent HOFFMAN UCP430 Polyester Wall-Mounted Enclosure 415×315×170 mm IP66
nVent HOFFMAN
nVent HOFFMAN OABP306013GE ABS Junction Box 300×600×132 mm IP66
Catalogue entry last verified: 2026-09-29. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy EFP220-115R5?
- EFP220-115R5 can be ordered from cballast.com as a nVent HOFFMAN catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this nVent HOFFMAN product?
- The manufacturer part number is EFP220-115R5.
- What is the HS code for EFP220-115R5?
- The customs tariff (HS) code for EFP220-115R5 is 8414.90.
- Who manufactures EFP220-115R5?
- EFP220-115R5 is a nVent HOFFMAN product in the Enclosures range.
- Is a datasheet available for EFP220-115R5?
- Yes — the EFP220-115R5 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for EFP220-115R5?
- The minimum order quantity is 1.
- Is EFP220-115R5 available?
- Yes — EFP220-115R5 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
