MOTION DETECTOR Relay 24VAC/DC 90°
Pricing
Request a quote
We reply within 24 hours
Product Description
Niko 41-279 Bevegelsesmelder HVAC PIR wall 90° 24V potfritt relay.
Technical Specifications
- Manufacturer part number (MPN)
- 41-279
- EAN / GTIN
- 5703102204318
- HS code
- 8536.90
- Sales unit
- pcs
- Package quantity
- 50 pcs
- Voltage
- 24 V AC
- Nominal voltage
- 24 V
- Colour
- White
- Width
- 52 mm
- Model
- Movement sensor
- Height
- 67 mm
- Depth
- 34 mm
- Connection type
- Screwed terminal
- Voltage type
- AC/DC
- Switch-off delay
- 1800 s
- Material quality
- Thermoplastic
- Max. reach frontally
- 15 m
- Max. reach sideways
- 15 m
- Max. switching power
- 0.12 W
- Temperature
- -20–50 °C
- Max. starting current
- 0.008 A
- Material
- Plastic
- Diameter reach on floor
- 15 m
- RAL-number (similar)
- 9010
- Scan angle
- 90 °
- Degree of protection (IP)
- IP20
- Surface finishing
- Matt
- Min. switch-on time
- 0.01 s
- Max. duty cycle
- 0.01 min
- Suitable for wall mounting
- Yes
- Optimum mounting height
- 2.5 m
- Number of switching zones
- 7
- With DALI interface
- No
- Min. starting current
- 0 A
- Min. depth of built-in installation box
- 0 mm
- Max. presence range
- 12 m²
- Sensor type
- Passive infrared
- Country of origin
- Denmark
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 5703102204318
- SAP 1000420136
- Code 835237
Product Documentation
