M12 male 0° / M12 male 0° D-cod. shielded PUR 1X4XAWG22 shielded gn UL/CSA 10M

Murrelektronik 7000-44511-7941000 M12 straight male for M12 straight male, D-coded, Ethernet, PUR 2x2xAWG22 shielded green UL/CSA, 10m.

Manufacturer part number (MPN)

7000-44511-7941000

Model designation

MSDAL0-DA-T794_10.0-ZS

EAN / GTIN

4048879328074

HS code

8544.42

EU customs tariff number

85444290

US customs tariff number

8544429090

Weight

0.660 kg

Country of origin

HU

Sales unit

pcs

Cable length

10.00 m

Side 1 - Family construction form

M12

Side 1 - No. of poles

4

Side 1 - Coding

D

Side 1 - Gender

male

Side 1 - Mounting method

inserted, screwed

Side 1 - Threaded hole

M12 x 1

Side 1 - Tightening torque

0.6 Nm

Side 1 - Width across flats

SW13

Side 1 - Cable outlet

straight

Side 1 - Material

PUR

Side 1 - Material contact

Copper alloy

Side 1 - Coating contact

gold plated

Side 1 - Degree of protection (EN IEC 60529)

IP67, IP66K, IP65

Side 2 - Family construction form

M12

Side 2 - No. of poles

4

Side 2 - Coding

D

Side 2 - Gender

male

Side 2 - Mounting method

inserted, screwed

Side 2 - Threaded hole

M12 x 1

Side 2 - Tightening torque

0.6 Nm

Side 2 - Width across flats

SW13

Side 2 - Cable outlet

straight

Side 2 - Material

PUR

Side 2 - Material contact

Copper alloy

Side 2 - Coating contact

gold plated

Side 2 - Degree of protection (EN IEC 60529)

IP67, IP66K, IP65

Electrical data | Supply - Operating voltage DC max.

60 V

Supply - Current operating per contact max.

1.5 A

Industrial Communication - Data transmission rate max.

100 Mbit/s

Industrial Communication - Transfer parameters

CAT5, Class D (ISO/IEC 11801:2002), (EN 50173-1)

Industrial communication | Ethernet functionality - duplex

Full duplex

Electrical - Degree of protection (EN IEC 60529)

IP67, IP66K, IP65

Electrical - Additional condition protection degree

inserted, screwed

Device protection | Electrical - Pollution Degree

3

Device protection | Electrical - Rated surge voltage

1.5 kV

Electrical - Material group (IEC 60664-1)

I

Mechanical data - Contour for corrugated hose

without

Mechanical data | Material data - housing

PUR

Mechanical data | Material data - Screw connection

Zinc die-casting

Mechanical data | Material data - Coating of fitting

nickel plated

Mechanical data | Mounting data - Mounting method

inserted, screwed, Shaking protection

Climatic - Operating temperature min.

-30 °C

Climatic - Operating temperature max.

85 °C

Climatic - Additional condition temperature range

depending on cable quality

Important installation notes - Note on bending radius

Attention: Observe the permissible bending radii when laying cables, as the IP protection class can be endangered by excessive bending forces.

Important installation notes - Note on strain relief

Protect the connectors by suitable measures from mechanical loads, e.g. by the usage of cable ties.

Conformity - Product standard

EN IEC 61076-2-101 (M12)

General data | Cable - Cable identification

794

General data | Cable - Function cable

Data

General data | Cable - Cable weigth

68.97 g/m

General data | Cable - UL AWM Style

20549 / 10578

Structure | Cable - Stranding

1 × 4 wires around core filler star-shaped twisted

Structure | Cable - Cable shielding (type)

copper braid, tinned

Structure | Cable - Cable shielding (coverage)

85 %

Structure | Cable - Banding

Fleece, Foil

Structure | Cable - Filler

Yes

Structure | Cable - Wire arrangement

AND, WH, YE, BU

Structure | Cable - Shield

shielded

Structure | Cable - Cable type

Industrial Ethernet Profinet Typ B, CAT5e

Wire data | Cable - Material wire insulation

PE

Wire data | Cable - Amount wires

4

Wire data | Cable - Outer diameter insulation

1.55 mm ± 0.05 mm

Wire data | Cable - Conductor crosssection (wire)

22 AWG

Wire data | Cable - Material conductor wire

Stranded copper wire, bare

Wire data | Cable - Core construction (wire)

7 x 30 AWG

Wire data | Cable - Ingredient freeness wire insulation

lead-free, CFC-free, halogen-free

Jacket data | Cable - Material jacket

PUR

Jacket data | Cable - Outer-diameter (jacket)

6.7 mm ± 5 %

Jacket data | Cable - Jacket Color

green / RAL 6018

Jacket data | Cable - Material inner jacket

FRNC

Jacket data | Cable - Color (inner jacket)

white

Jacket data | Cable - Freedom from ingredients (jacket)

lead-free, cadmium-free, CFC-free, halogen-free, silicone-free

Jacket data | Cable - Material property (jacket)

abrasion-resistant, low adhesion, good machinability, matte

Shield | Cable - Cable shielding (type)

copper braid, tinned

Shield | Cable - Cable shielding (coverage)

85 %

Electrical data | Cable - Conductor resistance (wire)

55.4 Ω/km @ 20 °C

Electrical data | Cable - Nominal voltage max.

300 V

Electrical data | Cable - Withstand voltage (wire - wire)

2 kV @ 60 s

Cable - Withstand voltage (wire - jacket)

2 kV @ 60 s

Cable - Withstand voltage (wire - shield)

2 kV @ 60 s

Cable - Current load capacity max. (wire)

4.8 A

Electrical data | Cable - Current load capacity (standard)

to DIN VDE 0298-4

Cable - Electrical capacity line constant (wire - wire)

52.000 pF/km

Electrical data | Cable - Isolation resistance

5.000 MΩ × km

Electrical data | Cable - Characteristic impedance

100 Ω ± 15 %

Temperature range | Cable - Operating temperature (static)

-40 °C … 80 °C

Cable - Operating temperature (dynamic)

-20 °C … 60 °C

Resistances | Cable - Flame resistance

UL 1581 § 1060, UL 1581 § 1090, UL 1581 § 1100

Resistances | Cable - Oil resistance

IEC 60811-404, NEMA WC55, IRM 901, IRM 902

Resistances | Cable - Ozone resistance

IEC 60811-403

Resistances | Cable - UV resistance

UL 1581 § 1200

Resistances | Cable - Other resistances

resistant to hydrolysis, resistant to microbes, MUD-resistant (NEK 606)

Resistances | Cable - Notes

application-related testing

Installation | Cable - Bending radius (fixed)

6 × Outer diameter

Installation | Cable - Bending radius (dynamic)

12 × Outer diameter

ETIM-5.0

EC002599

ETIM-6.0

EC002599

ETIM-7.0

EC002599

ETIM-8.0

EC002599

ETIM-9.0

EC002599

ETIM-10.0

EC002599

Packaging unit

1

ECLASS 14.0

27060307

HS Code

8544.42
