Melbye A4653G Insulated Flanged Fork (Spade) Terminal 4–6 mm² M5 (Yellow)
Pricing
Request a quote
We reply within 24 hours
Product Description
Melbye A4653G — insulated flanged fork (spade) terminal for a 4–6 mm² copper conductor, for an M5 screw stud (fork slot Ø 5.3 mm). Tinned 99.95% copper barrel with a brazed neck in a halogen-free polycarbonate easy-entry sleeve, colour-coded yellow for the conductor range. The open fork slot fits over a screw stud without removing the nut; crimped to stranded or fine-stranded copper conductors (IEC 60228) with matching Elpress/Abiko dies for terminal-block, contactor and distribution-equipment terminations.
Technical Specifications
- Type
- Insulated flanged fork (spade) terminal
- Conductor cross-section
- 4–6 mm²
- Stud size
- M5 (fork slot Ø 5.3 mm)
- Terminal form
- Fork (spade), open slot
- Insulation
- Halogen-free polycarbonate (PC) easy-entry sleeve
- Insulation colour code
- Yellow
- Material
- Copper 99.95%, tin-plated, brazed neck
- Conductor
- Stranded / fine-stranded copper (IEC 60228)
- Series
- A (pre-insulated)
- Manufacturer part number (MPN)
- A4653G
- EAN / GTIN
- 7070701016726
- Sales unit
- pcs
- HS code
- 8536.90
- Surface protection
- Tinned
- Total length
- 26.6 mm
- Max. current (Imax)
- 20 A
- Flange shape
- Fork shape
- For pull protected connections
- No
- Reel/roll packaging
- No
- Colour insulation
- Yellow
- Bolt dimension (metric)
- 5.5
- AWG-range
- 10–12
- Nominal cross section
- 4–6 mm²
- Suitable for fine strand conductors
- Yes
- Suitable for flat conductors
- No
- Suitable for high temperatures (to 650 °C)
- No
- Suitable for insulated varnish
- No
- Suitable for solid conductors
- Yes
- Suitable for stranded conductors
- Yes
- Suitable for round conductors
- Yes
- Sleeve form
- Short
- According to DIN
- No
- Country of origin
- Italy
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 7070701016726
- SAP 1000057174
- Code 8541921
Product Documentation
More from Melbye
Melbye
Bit set 37 parts (8802585)
Melbye
Railforbinder (2879100)
Melbye
Angle Bracket 60° EX 2X25-4X95
VF5170.04
Melbye
Melbye 8867638 Cable Entry Guide Bushing, Ø89 mm, with Rollers
Melbye
Letter - B, pack à 10 pcs
10407453
Melbye
Melbye 103/120/800 GRP Duct Draw Rod on Stand, Ø9 mm × 120 m
Melbye
ISO-Terminal with PIGG 5209/3
Melbye
Helmet Petzl Vertex red
8802492
Catalogue entry last verified: 2026-09-29. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy A4653G?
- A4653G can be ordered from cballast.com as a Melbye catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Melbye product?
- The manufacturer part number is A4653G.
- What is the HS code for A4653G?
- The customs tariff (HS) code for A4653G is 8536.90.
- Who manufactures A4653G?
- A4653G is a Melbye product in the Electrical Components range.
- Is a datasheet available for A4653G?
- Yes — the A4653G datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for A4653G?
- The minimum order quantity is 1.
- Is A4653G available?
- Yes — A4653G is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
