Melbye A4-12ET Insulated Wire-End Ferrule, 4 mm² / 12 mm (Grey)
Pricing
Request a quote
We reply within 24 hours
Product Description
Melbye A4-12ET — insulated wire-end ferrule (cord-end sleeve) for a 4 mm² stranded copper conductor, 12 mm crimp length. Insulation colour-coded Grey per DIN 46228-4. Tin-plated electrolytic copper barrel with a grey insulating collar, to DIN 46228-4; crimped to fine-stranded copper conductors (IEC 60228) for terminal-block and connector terminations.
Technical Specifications
- Product type
- Insulated wire-end ferrule (cord-end sleeve)
- Conductor cross-section
- 4 mm²
- Crimp length
- 12 mm
- Insulation collar Ø
- 4.4 mm
- Insulation colour code
- Grey
- Material
- Tin-plated electrolytic copper, insulated collar
- Standard
- DIN 46228-4
- Manufacturer part number (MPN)
- A4-12ET
- EAN / GTIN
- 7070701016016
- HS code
- 8536.90
- Sales unit
- pcs
- Colour
- Grey
- Sleeve length
- 12 mm
- Insulated
- Yes
- Halogen free
- No
- Surface protection
- Tinned
- Total length
- 19.7 mm
- Construction type
- Standard
- Nominal cross section
- 4 mm²
- For cables resistant to short circuit
- No
- Reel/roll packaging
- No
- With identification flag
- No
- AWG size
- 12
- Country of origin
- Taiwan
Standards & Compliance
- Standard
- DIN 46228-4
- Material
- Tin-plated electrolytic copper, insulated collar
- HS Code
- 8536.90
Cross References
- EAN 7070701016016
- SAP 1000048330
- Code 8799272
Product Documentation
More from Melbye
Melbye
Melbye A2565R Insulated Ring Terminal, 2.5 mm² M6 (Blue)
Melbye
Melbye Screw-Connector Heat-Shrink Joint 1 kV, 3x16-50 mm2
MPC-3
Melbye
Voltage Indicator for Railway Catenary 16 kV, 16 2/3 Hz
8880018
Melbye
Melbye SS-4 Heat-Shrink Joint for Screened 3-Core Cable, 50-150 mm2
Melbye
Shrink.with Adhesive Black 18,0-6,0mm
1835674
Melbye
Cable LUG 95-16 29 (KRF95-16)
Melbye
HEAT-SHRINK TUBING BLACK 51,0-25,4mm SR1F
SRIF 51,0-25,4
Melbye
Earthing Clamp JK 37
Catalogue entry last verified: 2026-09-29. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy A4-12ET?
- A4-12ET can be ordered from cballast.com as a Melbye catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Melbye product?
- The manufacturer part number is A4-12ET.
- What is the HS code for A4-12ET?
- The customs tariff (HS) code for A4-12ET is 8536.90.
- Who manufactures A4-12ET?
- A4-12ET is a Melbye product in the Electrical Components range.
- Is a datasheet available for A4-12ET?
- Yes — the A4-12ET datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for A4-12ET?
- The minimum order quantity is 1.
- Is A4-12ET available?
- Yes — A4-12ET is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
