Malthe Winje GWD4052 Residual Current Circuit Breaker (RCCB) — Type A, 2-Pole, 63 A, 30 mA, 2 Modules

A two-pole residual current circuit breaker rated 63 A with a 30 mA residual current setting, two modules wide. An RCCB disconnects the circuit when the current flowing out does not match the current returning — the signature of a fault to earth, whether through failed insulation or through a person. It provides no overcurrent protection of its own and is installed together with the circuit's MCB or fuse. It is a type A device: it responds to sinusoidal AC residual currents and to pulsating DC residual currents, which is the general-purpose requirement wherever ordinary electronic loads are present. At 30 mA it is rated for the protection of people against electric shock. Rated voltage 230 V, rated insulation voltage 500 V, short-circuit withstand 10 kA, IP20, terminals taking 10-35 mm² conductors, operating range -25 to 60 °C. Supplied by cBallast on quote-to-invoice terms; lead time and freight are quoted per RFQ against the destination Incoterm.

Manufacturer part number (MPN)

GWD4052

EAN / GTIN

8011564824188

HS code

8536.90

Sales unit

pcs

Mounting method

DIN rail

Colour

Grey

Voltage type

AC

Built-in depth

72 mm

Rated current

63 A

Rated voltage

230 V

Rated insulation voltage Ui

500 V

Number of poles

2

Rated fault current

0.03 A

Leakage current type

A

Selective protection

No

Short-circuit breaking capacity (Icw)

10 kA

Surge current capacity

0.25 kA

Pollution degree

2

Width in number of modular spacings

2

Short-time delayed tripping

No

Explosion-proof

No

Frequency

50/60 Hz

Degree of protection (IP)

IP20

Connectable conductor cross section solid-core

10–35 mm²

Connectable conductor cross section multi-wired

10–35 mm²

With interlocking device

No

Ambient temperature during operating

-25–60 °C

Additional equipment possible

Yes

Device width

36 mm

Device height

85 mm

Device depth

72 mm

Rated impulse withstand voltage Uimp

4 kV

Country of origin

Italy

Device type

Residual current circuit breaker (RCCB), no integral overcurrent protection

Rated residual current (IΔn)

30 mA

Residual current type

Type A

Protection purpose

Protection of people against electric shock

Width in modules

2

HS Code

8536.90

• EAN 8011564824188
• SAP 1200927942
• Code 84213495
