Loose flange aluminium epoxy RAL9016 white - 150, 10bar, 168,3mm
Pricing
Request a quote
We reply within 24 hours
Product Description
Loose flange aluminium epoxy RAL9016 white. Loose flanges DIN/ISO (Technique / Acid-resistant and Stainless fittings / Flanger). Principal data: dn dimension 150, pressure pn 10 bar, for pipes with outer diameter 168.3 mm. Supplied under manufacturer part number GL81757716, HS code 7609.00, country of origin India.
Technical Specifications
- Product type
- Loose flanges DIN/ISO
- Product group
- Acid-resistant and Stainless fittings
- DN dimension
- 150
- Pressure PN
- 10 bar
- For pipes with outer diameter
- 168.3 mm
- Number of bolt holes
- 8 pcs
- Bolt hole diameter
- 22 mm
- Bolt circle diameter
- 240 mm
- Flange thickness
- 18 mm
- Diameter
- 285 mm
- Inner diameter
- 173 mm
- Tolerance
- DIN2642 PN10
- Weight
- 1.8 kg
- REACH SVHC substance above 0.1%
- None
- Carbon footprint (EPD)
- 0.0050 kg CO2e per pcs
- Environmental declaration
- LCA
- Country of origin
- India
- Customs tariff code (EU CN)
- 76090000
- HS code
- 7609.00
- Manufacturer part number
- GL81757716
Standards & Compliance
- HS Code
- 7609.00
Cross References
- MPN GL81757716
