Loose flange acid-resistant - 300, 10bar, 304mm
Pricing
Request a quote
We reply within 24 hours
Product Description
Loose flange acid-resistant. Loose flanges DIN/ISO (Technique / Acid-resistant and Stainless fittings / Flanger). Principal data: dn dimension 300, pressure pn 10 bar, for pipes with outer diameter 304 mm. Supplied under manufacturer part number GL13258633, HS code 7307.21, country of origin India.
Technical Specifications
- Product type
- Loose flanges DIN/ISO Product group: Acid-resistant and Stainless fittings DN dimension: 300 Pressure PN: 10 bar For pipes with outer diameter: 304 mm Number of bolt holes: 12 pcs Bolt dimension: 20 mm Bolt hole diameter: 22 mm Bolt circle diameter: 400 mm Flange thickness: 26 mm Diameter: 445 mm Steel quality: 4404 Tolerance: EN-1092 type 02A material certificate: EN 10204 3.1 Weight: 12.8 kg Inner diameter: 313 mm E dimension: 8 mm REACH SVHC substance above 0.1%: None Carbon footprint (EPD): 0.0403 kg CO2e per pcs Environmental declaration: LCA Country of origin: India Customs tariff code (EU CN): 73072100 HS code: 7307.21 Manufacturer part number: GL13258633
Standards & Compliance
- HS Code
- 7307.21
Cross References
- MPN GL13258633
Product Documentation
More from Generic
Generic
DIN 931 Hex Bolt electro-galvanised FZB 10.9 - M12, 140mm, 50 pcs, 36mm thread
10931121402
Generic
DIN 6921 Flange Bolt stainless A2 KL. 70 - M6, 50mm, 200PCS, 18mm
6921060504
Generic
Allen Screw low cylindrical head electro-galvanised FZB 8.8 - M8, 30mm, 200 pcs
7984080302
Generic
ISO 7380-1 Button-head Socket Screw acid-resistant A4 - M3, 25mm, 1000 pcs
7380030256
Generic
DIN 1481 Spring Pin stainless A1 - 6mm, 60mm
14810600604
Generic
O-ring NBR (nitrile) - 25mm, Shore 70, 6,00mm
236713
Generic
SPA V-belt pulley - 125mm, 6PCS, 2012
AT01256
Generic
Nipple acid-resistant BSPT - 3/8", 3/8", Nipple, Nipple, BSPT, BSPT
TB11382180
Catalogue entry last verified: 2026-09-30. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy GL13258633?
- GL13258633 can be ordered from cballast.com: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this product?
- The manufacturer part number is GL13258633.
- What is the HS code for GL13258633?
- The customs tariff (HS) code for GL13258633 is 7307.21.
- Is a datasheet available for GL13258633?
- Yes — the GL13258633 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for GL13258633?
- The minimum order quantity is 1.
- Is GL13258633 available?
- Yes — GL13258633 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
- How do I get a price for GL13258633?
- Request a quotation with the quote button on this page or by email to sales@cballast.com — we reply within 24 hours with price, availability and lead time.
