Connection cable suitable for Keyence ICA-CH10RX PUR, 10XD (MAT904194296)

igus Connection cable suitable for Keyence ICA-CH10RX PUR, 10XD (MAT904194296) is listed under Safety & Detection / Tools. Copper index kg/km: 66 kg/km; Shipping weight (kg or kg/m): 0.121; Outer diameter (d) max. mm: 8.5 mm; Weight per km: 101 kg/km; Min. bend radius, e-chain: 85 mm; Min. bend radius, flexible: 68 mm.

Manufacturer part number (MPN)

ICA-CH10RX

Brand

IGUS

Category

Tools

Number of cores and conductor nominal cross-section

(25x0.14)C

Copper index kg/km

66 kg/km

Shipping weight (kg or kg/m)

0.121

Outer diameter (d) max. mm

8.5 mm

Weight per km

101 kg/km

Min. bend radius, e-chain (factor)

10 x d

Min. bend radius, e-chain

85 mm

Min. bend radius, flexible (factor)

8 x d

Min. bend radius, flexible

68 mm

Min. bend radius, fixed (factor)

5 x d

Min. bend radius, fixed

42.5 mm

Temperature e-chain®

-25°C up to +80°C

Temperature, flexible

-40°C to +80°C (according to DIN EN 60811-504)

Temperature, fixed

-50°C to +80°C (according to DIN EN 50305)

v max. unsupported (speed)

3 m/s

v max. gliding (speed)

2 m/s

a max. (acceleration)

20 m/s²

travel length

Travels up to 50 m

torsion

No Torsion

Conductor

Very finely stranded special conductors of a particularly bend-resistant design, made of bare copper wires.

Core insulation

Mechanically high-quality TPE mixture.

Core stranding

The individual cores are wound in layers with a short pitch length.

Overall shield

Extremely flexible braiding made of tinned copper wires. Coverage linear approx. 70%, optical approx. 90%

Outer jacket

Low-adhesion, halogen-free, highly abrasion-resistant PUR mixture, adapted to suit the requirements in e-chains® (according to DIN EN 50363-10-2).

Outer jacket colour

Window grey (comparable to RAL 7040)

Nominal voltage

300/300V (according to DIN VDE 0298-3)

Test voltage

1500V (according to DIN EN 50395)

UV resistance

Medium

Oil resistance

Oil-resistant (according to DIN EN 50363-10-2), Class 3

Silicone-free

Free from silicone which can affect paint adhesion (according to PV 3.10.7 – status 1992)

Halogen-free

According to DIN EN 60754

EAC

Certificate No. RU C-DE.ME77.B.00300/19

Lead-free

According to 2011/65/EU (RoHs-II/RoHS-III)

Cleanroom

According to ISO Class 1 The outer jacket material of this series complies with CF77.UL.05.12.D - tested by IPA according to standard DIN EN ISO 14644-1

CE

According to 2014/35/EU

UL/CSA AWM

val_ul_csa_75

UL verified

Certificate no. V293650: "igus 4-year chainflex cable guarantee and service life calculator based on 2 billion test cycles per year"

Flame-retardant

According to IEC 60332-1-2, Cable Flame, VW-1, FT1, FT2/Horizontal Flame

DNV

Type approval certificate TAE00003X3

NFPA

According to NFPA 79-2018, chapter 12.9

Offshore

MUD-resistant according to NEK 606 - status 2018

HS Code

8544.42
