Heat Shrink Tubing HA47 130/36 mm Black 1 m

Hellermann 321-21300 Thick-walled heat-shrink tubing with adhesive, HA47 130/36mm Black 1m.

Manufacturer part number (MPN)

321-21300 EAN / GTIN: 4031026240428 Sales unit: pcs Package quantity: 3 pcs OEM part description: HA47-130/36-PO-X-BK Type: HA47-130/36 Product family: HA47 - thick wall adhesive lined Serration: Thick-Wall material: Polyolefin, cross-linked (PO-X) Colour: Black (BK) Length: 1.0 m Wall thickness: 4.2 mm Supplied diameter (min.): 130.0 mm Recovered diameter (max.): 36.0 mm Operating temperature: -55 °C to +110 °C Halogen-free: Yes RoHS compliant: Yes ELV compliant (Article 4-2): Yes Hazardous goods: No Weight per unit: 0.677166 kg Packed in: pcs. Country of origin: CN Customs tariff number: 39173200 ETIM 9.0 class: EC000217 UNSPSC code: 39121723 Behaviour At Low Temperature: not cracking Behaviour at Heat Shock: not cracking, not fluid, not dripping Behaviour at low Temperature test method: ASTM D2671 Elongation At Heat Aging: 300 % Heat Aging Test: 168h/150°C Heat Aging test method: ASTM D2671 Heat Shock Test: 4h/225°C minimum Tensile Strength At Heat Aging: 12 MPa Printable: No Shrink Ratio: up to 4:1 With inner glue (Yes/No): Yes Model: Thick-walled Wall thickness after shrinking: 4.3 mm Inner diameter before heat-shrink: 130 mm Inner diameter after heat-shrink: 36 mm Transparent: No Shrink rate: 4:1 UL approval: No

HS Code

3917.32

• EAN 4031026240428
• SAP 1200415739
• Code 82458995
