Heat Shrink Tubing HA47 45/12 mm Black 1 m

Hellermann 321-50450 Tredux HA47 thick-walled with adhesive, black 1m.

Manufacturer part number (MPN)

321-50450

EAN / GTIN

4031026239880

Sales unit

pcs

Package quantity

4 pcs

OEM part description

TREDUX-HA47-45/12-PO-X-BK

Type

TREDUX-HA47-45/12

Product family

TREDUX HA47 - thick wall adhesive lined

Serration

Thick-Wall

Material

Polyolefin, cross-linked (PO-X)

Colour

Black (BK)

Length

1.0 m

Wall thickness

4.1 mm

Supplied diameter (min.)

45.0 mm

Recovered diameter (max.)

12.0 mm

Operating temperature

-55 °C to +110 °C

Halogen-free

Yes

RoHS compliant

Yes

ELV compliant (Article 4-2)

Yes

UL recognised (US and Canada)

No

Hazardous goods

No

Weight per unit

0.22624 kg

Packed in

pcs.

Inner pack quantity

4

Inner pack type

carton

Country of origin

CN

Customs tariff number

39173200

ETIM 9.0 class

EC000217

UNSPSC code

39121723

Printable

No

Shrink Ratio

up to 4:1

Voltage range

Low Voltage

With inner glue (Yes/No)

Yes

For Object Outside Diameter

18.6-38.4 mm

Longitudinal Change After Shrinkage

-10% max.

Nominal ⌀

45 mm

Wire Size Range (mm²)

18.6-38.4 mm²

Model

Thick-walled

Wall thickness after shrinking

4.1 mm

Inner diameter before heat-shrink

45 mm

Inner diameter after heat-shrink

12 mm

Transparent

No

Shrink rate

4:1

UL approval

No

HS Code

3917.32

• EAN 4031026239880
• SAP 1000042483
• Code 8774545
